Grid Inverter SMA Sunny Tripower Three-Phase 8 kVA – STP8.0-3AV-40
€1,338.26
Tax included
Not sure what you need?
Three simple questions, and we tell you what suits you.
Let us guide you →
STP 8.0-3AV-40
0768563816253
The SMA STP8.0-3AV-40 three-phase inverter (Sunny Tripower 8.0 tl int blue) is designed for residential photovoltaic installations and medium-sized sites requiring stable, optimised power generation. Power: 8 kVA, with three-phase feed-in and a grid voltage of 230/400 V.
- PV optimisation: OptiTrac Global Peak to maintain yield on partially shaded rooftops.
- Scalability: integrated TS4-R communication for panel optimisation, with the option to add TS4-R optimisers as required.
- Installation: compact design for easy installation and simplified cabling.
- Performance: claimed efficiency of up to 98.3 per cent (97.7 per cent under European efficiency standards).
- Scalable system: compatible with SMA smart energy management and storage solutions.
A good choice if you’re looking for a reliable, three-phase Sunny Tripower 8 kVA inverter suitable for complex roof configurations.
Product available to order only
📦 Disponible en kit complet
18.0 kWp Self-Consumption/Feed-in Solar Kit – Tri 10.0... — €6,371.75
SMA Sunny Tripower 8 kVA : Solar intelligence for optimised production
The new Sunny Tripower 8.0-10.0 guarantees maximum energy production for households. Its compact design makes installation quick and easy. And to meet the specific requirements of rooftop installations, TS4-R optimizers can be added easily and at your convenience, for example in the event of shading. Compatible with the latest communication standards, the inverter can be reliably equipped with SMA's intelligent energy management and storage solutions at any time.
Quick and easy installation
With its low weight, this three-phase inverter is quick and compact to install.
Intelligent solar power generation
The Sunny Tripower is unique: proven features such as OptiTrac Global Peak are now accompanied by integrated TS4-R communication for panel optimization. Shadows on the photovoltaic panel are no longer a problem. In the event of light shading, the integrated OptiTrac Global Peak shading management system ensures maximum production. In the case of more severe shading or complex roofs, TS4-R optimizers, which are simple and selective to install, ensure optimum production.
Expandable at any time
With Sunny Tripower, photovoltaic system owners and installers always have a state-of-the-art solution at their disposal. Should the household's use of solar power increase, Sunny Tripower systems can be upgraded at any time with SMA's intelligent energy management and storage solutions.
Features
| Model | Sunny Tripower 8.0 | Sunny Tripower 10.0 |
| Input (DC) |
| Max. power of photovoltaic generator | 15000 Wp | |
| Max. input voltage | 1000 | |
| V | ||
| MPP voltage range | 260 V to 800 V | 320 V to 800 V |
| Rated input voltage | |
| V | |
| Min. input voltage / start-up input voltage Max. input current A / input B | 125 V / 150 V | |
| Min. input current./ starting input voltage | 20 A /12 A | |
| Max. short-circuit current. | ||
| input A / input B | 30 A / 18 A | |
| Number of independent MPP inputs / strings per MPP input | |
| A:2 ; B:1 | |
| Output (AC) |
| Rated power (for 230 V, 50 Hz) | |
| W | 10000 W |
| Max. apparent AC power | |
| VA | 10000 VA |
| Rated AC voltage | |
| ; 220 V / 380 V 3/N/PE; 230 V / 400 V 3/N/PE; | |
| 240 V / 415 V | |
| AC voltage range | 180 V to 280 V | |
| AC mains frequency / range | 50 Hz / 45 Hz to 55 Hz 60 Hz / 55 Hz to 65 Hz | |
| Rated mains frequency / rated mains voltage | 50 Hz / 230 V | |
| Maximum output current |
| 12,1A |
| 14.5 A |
| Power factor at rated power / adjustable phase shift factor | |
| / 0.8 inductive to 0.8 capacitive | |
| Injection phases / connection phases |
| Efficiency |
| Max. efficiency. | ||
| / European efficiency | 98.3 % / 97.7 % | 98.3 % / 98.0 |
| Protective devices |
| Input-side disconnection device | ● | |
| Earth fault monitoring / mains monitoring | ●/● | |
| DC reverse polarity protection / AC short-circuit resistance / galvanic separation Fault current monitoring unit, | ||
| sensitive to all currents | ●/●/- | |
| Protection class (to IEC 62103) / overvoltage category (to IEC 60664-1) General data | |
| / III | |
| General data |
| Dimensions (W / H / D) | 460 mm / 497 mm / 176 mm (18, | |
| inches / 19.6 inches / 6.9 inches) |
| Weight | 20.5 kg (45.2 lb) | |
| Operating temperature range | -25 °C to +60 °C (-13 °F to +140 °F) | |
| Noise emissions, typical | 30 dB(A) | |
| Autoconsumption (night) | |
| ,0 W | |
| Topology / cooling system | Transformerless / Convection | |
| Protection class (to IEC 60529) | IP65 | |
| Climatic class (to IEC 60721-3-4) |
| Maximum permissible value for relative air humidity (non-condensing) | 100,00% | |
| Equipment |
| DC | ||
| / AC connection | SUNCLIX / AC plug | |
| Shade management : | ||
| OptiTrac Global Peak / TS4-R | ●/ ○ | |
| Warranty: 5 / 10 / 15 years | ●/ ○/ ○ | |
| Certifications and approvals (others on request) | AS 4777.2, C10/11, CE, CEI 0-21, EN 50438, G59/3-4, G83/2-1, DIN EN 62109 / IEC 62109, NEN-EN50438, ÖVE/ÖNORM E 8001-4-712 & TOR D4, PPC, PPDS, RD1699, SI4777, TR3.2.1, UTE C15-712, VDE-AR-N 4105, VDE0126-1-1, VFR 2014 |
|
| Type designation | STP8.0-3AV-40 | STP10.0-3AV-40 |
STP 8.0-3AV-40
Data sheet
- Inverter power in VA
- 8000 VA
- Max.PV Input Power
- 15000Wp
- Max. solar input voltage
- 1000 V
- Phase
- Triphasé
- Number of MPPT
- 2 MPPT
- Width
- 460 mm
- MPPT voltage range
- 260 V to 800 V
- PV input current
- 20 A / 12 A
Specific References
- UPC
- 768563816253
- EAN13
- 0768563816253
