Rack 19‘’ 12U wall cabinet

"Ergonomic battery storage solution

Black laminated steel storage cabinet for your batteries.

Technical summary

Drilling for 12cm fan on top panel (fan not included). - Holes in back plate to fix cabinet to wall. - Cabinet depth 600mm. - Are delivered to the customer fully assembled and packaged, ready for installation.

Rack 19 " 12U range wall-mounted and outdoor cabinet wall size 600 mm (W) x 600 (D) x 635 (H).

Interior racks are configurable in depth, although the default value is supplied fitted at a distance of 315 mm between them.

The distance from the front frame to the bottom of the cabinet (useful bottom) could be up to 515 mm, maximum frame advancement.

Specifications

For a complete rack with 19" front and rear, adjustable in depth to fit any guiding structure of need. Glass door security gives a more attractive design and key lock.

180-degree door opening. Holes for cable routing in top and bottom panel.

Cable holes can be left open or closed with a metal plate.

Features

- Welded frame, reliable structure.
- Reversible 5 mm tempered glass entrance door with lock.
- Removable side panels with side pins, side locks optional for protection.
- Free-standing or wall-mounted.
- Cable entries on top cover and bottom panel.
- Weight: 26 Kg.
- Product dimensions: Width: 60 x Depth: 60 x Height: 63.5 cm.
- Material: SPCC cold-rolled steel
- Thickness: mounting rails: 1.5mm; others: 1.2mm
- Surface finish: degreasing, pickling, phosphorescent, powder coating.
- Static load capacity: 60Kgs
