Solar cable extension 2x6 mm² with 4x MC4 connectors (per meter)
€10.87
Tax included
Allonge-cable-6mm²
0768563817960
This extension cable allows you to simply increase the distance between your panels and the rest of the installation. This extension lead consists of 2 separate 2X6mm² cables.
Length : 1m
Select another length in the options
"Solar cable extension 2x6mm² "
6 mm² solar cable extension for photovoltaic systems.
Sold by the meter.
This extension cable allows you to simply increase the distance for indoor and outdoor photovoltaic applications for flexible or fixed installations, in compliance with 2 Pfg 1169/08.2007 and UTE C32-502.
Main features :
1. conductor :
- Flexible tinned copper class 5 to IEC 60228.
2. insulation :
- Polyolefin
3. Sheathing :
- Polyolefin
- Black color
Technical specifications :
1. Construction characteristics :
- Core flexibility: Flexible class 5
- Halogen-free: IEC 60754-1
2. Electrical data :
- Rated operating voltage Uo/U (Um) : 0.6 / 1 kV
3. Operating characteristics :
- Low smoke: IEC 61034-2
- Ozone resistance: yes
- Smoke corrosivity: IEC 60754-2
- Maximum core temperature: 120°C
- Ambient operating temperature range: -40° to 90°C
- Weather resistance: excellent
- Non-flame propagating: IEC 60332-1
1. conductor :
- Flexible tinned copper class 5 to IEC 60228.
2. insulation :
- Polyolefin
3. Sheathing :
- Polyolefin
- Black color
Technical specifications :
1. Construction characteristics :
- Core flexibility: Flexible class 5
- Halogen-free: IEC 60754-1
2. Electrical data :
- Rated operating voltage Uo/U (Um) : 0.6 / 1 kV
3. Operating characteristics :
- Low smoke: IEC 61034-2
- Ozone resistance: yes
- Smoke corrosivity: IEC 60754-2
- Maximum core temperature: 120°C
- Ambient operating temperature range: -40° to 90°C
- Weather resistance: excellent
- Non-flame propagating: IEC 60332-1
Allonge-cable-6mm²
Data sheet
- Cables and connectors
- Allonge câble solaire
Specific References
- UPC
- 768563817960
- EAN13
- 0768563817960
New
Solar cable extension 2x6 mm² with 4x MC4 connectors (per meter) — Mounting and accessories
Solar cable extension 2x6 mm² with 4x MC4 connectors (per meter) by Wattuneed is available in our Mounting and accessories catalog. Technical specifications: cables and connectors: Allonge câble solaire. Product weight: 0.2 kg. Reference: Allonge-cable-6mm².
