Onduleur triphasé SMA Sunny Tripower STP 10 kVA TL INT BLUE
Onduleur triphasé SMA Sunny Tripower STP 10 kVA TL INT BLUE
Three-phase inverter SMA Sunny Tripower STP 10.0 TL INT BLUE
Onduleur triphasé SMA Sunny Tripower STP 10 kVA TL INT BLUE
Onduleur triphasé SMA Sunny Tripower STP 10 kVA TL INT BLUE
Three-phase inverter SMA Sunny Tripower STP 10.0 TL INT BLUE

Three-phase inverter SMA Sunny Tripower STP 10 kVA TL INT BLUE

€2,470.40
Tax included
STP 10.0-3AV-40
0768563816260

SMA Sunny Tripower 10 kVA Inverter: Optimize Your Solar Energy Production

The three-phase SMA Sunny Tripower 10 kVA inverter is designed to maximize the efficiency of your solar panels. With its advanced technology and flexibility, it adapts to all configurations and guarantees maximum power production, even in shaded conditions.

Why choose the SMA Sunny Tripower 10 kVA inverter?

  • Exceptional Efficiency: Energy production optimization with OptiTrac Global Peak.
  • Flexibility: Compatible with TS4-R optimizers for precise shading management.
  • Easy Installation: Compact and lightweight for a quick installation.
  • Future-Proof: Ready for integration with storage and smart energy management solutions.

Key Advantages:

  • Optimized Self-Consumption: Maximize your solar energy consumption.
  • Reliability and Durability: Benefit from a quality product designed to last.
  • Simplified Installation: Quick and easy installation with its compact design.

SMA Sunny Tripower 10 kVA: The Future of Solar Energy Production.

Comments (0)

No customer reviews for the moment.

SMA Sunny Tripower 10 kVA : Maximise your solar production, even in shaded conditions

Onduleur triphasé SMA Sunny Tripower STP 10.0 TL INT BLUEThe new Sunny Tripower 8.0-10.0 guarantees maximum energy production for households. Its compact design makes installation quick and easy. And to meet the specific requirements of rooftop installations, TS4-R optimizers can be added easily and at your convenience, for example in the event of shading. Compatible with the latest communication standards, the inverter can be reliably equipped with SMA's intelligent energy management and storage solutions at any time.

Quick and easy installation

With its low weight, this three-phase inverter is quick and compact to install.

Production intelligente d’électricité solaire

Intelligent solar power generation

The Sunny Tripower is unique: tried-and-tested features such as OptiTrac Global Peak are now accompanied by integrated TS4-R communication for panel optimization. Shadows on the photovoltaic panel are no longer a problem. In the event of light shading, the integrated OptiTrac Global Peak shading management system ensures maximum production. In the case of more severe shading or complex roofs, TS4-R optimizers, which are simple and selective to install, ensure optimum production.

Expandable at any time

With Sunny Tripower, photovoltaic system owners and installers always have a state-of-the-art solution at their disposal. Should the household's use of solar power increase, Sunny Tripower systems can be upgraded at any time with SMA's intelligent energy management and storage solutions.

Features

Model Sunny Tripower 8.0 Sunny Tripower 10.0
Input (DC)
Max. power of photovoltaic generator 15000 Wp
Max. input voltage 1000
V
MPP voltage range 260 V to 800 V 320 V to 800 V
Rated input voltage
V
Min. input voltage / start-up input voltage Max. input current A / input B 125 V / 150 V
Min. input current./ starting input voltage 20 A /12 A
Max. short-circuit current.
input A / input B 30 A / 18 A
Number of independent MPP inputs / strings per MPP input
A:2 ; B:1
Output (AC)
Rated power (for 230 V, 50 Hz)
W 10000 W
Max. apparent AC power
VA 10000 VA
Rated AC voltage
; 220 V / 380 V 3/N/PE; 230 V / 400 V 3/N/PE;
240 V / 415 V
AC voltage range 180 V to 280 V
AC mains frequency / range 50 Hz / 45 Hz to 55 Hz 60 Hz / 55 Hz to 65 Hz
Rated mains frequency / rated mains voltage 50 Hz / 230 V
Maximum output current
12,1A
14.5 A
Power factor at rated power / adjustable phase shift factor
/ 0.8 inductive to 0.8 capacitive
Injection phases / connection phases
Efficiency
Max. efficiency.
/ European efficiency 98.3 % / 97.7 % 98.3 % / 98.0
Protective devices
Input-side disconnection device ●
Earth fault monitoring / mains monitoring ●/●
DC reverse polarity protection / AC short-circuit resistance / galvanic separation Fault current monitoring unit,
sensitive to all currents ●/●/-
Protection class (to IEC 62103) / overvoltage category (to IEC 60664-1) General data
/ III
General data
Dimensions (W / H / D) 460 mm / 497 mm / 176 mm (18,
1
inches / 19.6 inches / 6.9 inches)
Weight 20.5 kg (45.2 lb)
Operating temperature range -25 °C to +60 °C (-13 °F to +140 °F)
Noise emissions, typical 30 dB(A)
Autoconsumption (night)
,0 W
Topology / cooling system Transformerless / Convection
Protection class (to IEC 60529) IP65
Climatic class (to IEC 60721-3-4)
Maximum permissible value for relative air humidity (non-condensing) 100,00%
Equipment
DC
/ AC connection SUNCLIX / AC plug
Shade management :
OptiTrac Global Peak / TS4-R ●/ ○
Warranty: 5 / 10 / 15 years ●/ ○/ ○
Certifications and approvals (others on request) AS 4777.2, C10/11, CE, CEI 0-21, EN 50438, G59/3-4, G83/2-1,
DIN EN 62109 / IEC 62109, NEN-EN50438, ÖVE/ÖNORM E 8001-4-712 & TOR D4, PPC, PPDS, RD1699, SI4777, TR3.2.1, UTE C15-712, VDE-AR-N 4105, VDE0126-1-1, VFR 2014
Type designation STP8.0-3AV-40 STP10.0-3AV-40
STP 10.0-3AV-40

Data sheet

Inverter power
10000 VA
Max. solar input voltage
1000 V
Phase
Triphasé
Width
460 mm
Height
497 mm
Thickness
176 mm
Video Youtube 1 - ID
XrSVcrtJ2wA
Video Youtube 2 - ID
M6N79eT28WU
Video Youtube 3 - ID
zQH0cbvMwj8

Specific References

UPC
768563816260
EAN13
0768563816260
New
