Multisolar 30kW Hybrid Inverter View full size

Multisolar 30kW Hybrid Inverter

Wattuneed

7 834,75 € tax incl.

This inverter is integrated with an isolation transformer to provide pure power to connected devices. It can also operate in parallel with 4 units and extend their existing rated power by adding inverters.

More details

More info

Multisolar 30kW Hybrid Inverter



This INVERTer is integrated with an isolation transformer to provide pure power to connected devices. It can also operate in parallel with 4 units and extend their existing rated power by adding inverters.


Main features


• Pure sinusoidal output
• Self-consumption and injection on the network
• Programmable supply priority for PV, battery or network
• True galvanic insulated transformer design
• User-adjustable charging current
• Programmanles mutliple modes of operation: network connection, off-network and network connection with backup
• Built-in timer for various on/off modes of operation
• Mutliple communication for USB, RS-232, Modbus and SNMP
• Monitoring software for real-time display and status monitoring
• Parallel operation up to 4 units



Depending on the different energy sources, this hybrid inverter is designed to generate continuous energy from pv modules (solar panels), battery and electricity. continuous power supply from the PV modules (solar panels), the battery and the grid. When the MPP input voltage of the PV modules is within an acceptable range (see specifications for details), this INVERTER is capable of generating power to power the grid (public service) and charge the battery


Technical specifications



ModelMultisolar 30 kW
Maximum PV input power45 kW
Rated output power30 kW
Maximum load power30 kW
Network operation
PV (DC) input
Nominal DC Voltage/Maximum DC Voltage
720 VDC / 950 VDC
Starting voltage / Initial supply voltage
500 VDC / 550 VDC
Mpp Voltage Range
460 VDC~900 VDC
MPP voltage range at full power
625 VDC~900 VDC
Number of MPP trackers / Maximum input current1/72A
Network Output (CA)
Nominal output
230 VAC (P-N) / 400 VAC (P-P)
Output voltage range
195.5 - 253 VAC per phase
Output frequency range
49~51 Hz or 59.3~60.5 Hz
Nominal output current
43.5 A per phase
Power factor1
Yield
Maximum conversion yield (DC/AC)95%
Off-grid operation
AC input
AC starting voltage/Auto restart voltage
150-170 VAC per phase / 180 VAC per phase
Acceptable input voltage range
170-280 VAC per phase
Maximum AC input current
43.5 A per phase
PV (DC) input
Maximum DC Power/ Maximum DC Voltage
45 kW / 950 VDC
MPP voltage range
460 VDC ~900 VDC
Number of MPP trackers/Maximum Input Current1/72 A
Battery Mode Output (AC)
Nominal output voltage
230 VAC (P-N)/400 VAC (P-P)
Output waveform
Pure sine wave
Performance (CC to CA)>91%
Hybrid operation
PV (DC) input
Nominal DC voltage / Maximum DC voltage
720 VDC / 950 VDC
Starting voltage / Initial supply voltage
500 VDC / 550 VDC
MPP voltage range
460 VDC~900 VDC
Number of MPP trackers / Maximum input current1/72a
Network Output (AC)
Nominal output voltage
230 VAC (P-N) / 400 VAC (P-P)
Output voltage range
195.5 - 253 VAC per phase
Output frequency range
49~51 Hz or 59.3~60.5 Hz
Nominal output current43.5 by phase
Power factor1
AC input
Ac start voltage/restart voltage
150 - 170 VAC per phase / 180 VAC per phase
Acceptable input voltage range
170 - 280 VAC per phase
Maximum AC input current
43.5 A per phase
Exiting battery mode (AC)
Nominal output voltage
230VAC (P-N) / 400 VAC (P-P)
Performance (CD to HQ)>91%
Battery and charger
Nominal battery voltage/charging voltage range
384 VDC / 384 VDC ~480 VDC
Maximum load current80A
General
Physics
Dimension, DxWxH (mm)430x715x1021
Net weight (kgs)223
Interface
Communication portRS-233/USB
Smart slot
Optional SNMP, GPRS, WiFi, Modbus cards available
Environment
humidity
0~90% RH (Seamless)
Operating temperature-10 to 55°C
Altitude0~1000 m
