Multisolar 30kW hybrid inverter
$5,611.7
multisolar-30
0768563819032
Multisolar 30kW Hybrid Inverter:
The Multisolar 30kW hybrid inverter is the ideal solution to optimize your solar energy production. Thanks to its advanced design, it allows you to benefit from maximum self-consumption by prioritizing the energy produced by your solar panels. Moreover, by combining solar and grid energy, it ensures continuous electricity supply to your home or business, even in the event of a power outage.
Why choose this inverter?
- Flexibility: Adapt your system to your needs thanks to its multiple operating modes (grid, off-grid, backup).
- Reliability: Benefit from quality power supply thanks to its pure sine wave output and robust design.
- Savings: Significantly reduce your electricity bill by consuming the energy you produce.
- Scalability: Increase the power of your installation by connecting up to 4 units in parallel.
The benefits of self-consumption:
- Energy independence: Reduce your dependence on the electricity grid.
- Savings: Enjoy better purchase rates for the energy injected into the grid.
- Property value: Increase the value of your property with a high-performance solar installation.
Ready to take the big step toward self-consumption?
Feel free to request a personalized quote or contact our experts for any questions.
Multisolar 30kW hybrid inverter: energy optimisation and flexibility
This inverter is integrated with an isolation transformer to provide pure power to connected devices. It can also operate in parallel with 4 units and extend their existing power ratings by adding inverters.
Key features
- Pure sinusoidal output
- Self-consumption and grid injection
- Programmable supply priority for PV, battery or grid
- True galvanically isolated transformer design
- User-adjustable load current
- Programmable multiple operating modes: grid-connected, off-grid and grid-connected with backup
- Integrated timer for various on/off operating modes
- Versatile communication for USB, RS-232, Modbus and SNMP
- Monitoring software for real-time status display and control
- Parallel operation of up to 4 units
Depending on the different energy sources, this hybrid inverter is designed to generate continuous power from the PV modules (solar panels), the battery and electricity. continuous power from the PV modules (solar panels), the battery and the grid. When the MPP input voltage of the PV modules is within an acceptable range (see specifications for details), this inverter is capable of generating power to supply the grid (utility) and charge the battery.
Technical specifications
| Model | Multisolar 30kW |
| Maximum PV input power | 45 kW |
| Nominal output power | 30 kW |
| Maximum charging power | 30 |
| kW |
| Grid operation |
| PV input (DC) |
| Nominal DC voltage/Maximum DC voltage |
720 VDC / 950 VDC |
| Start-up voltage / |
| Initial supply voltage |
500 VDC / 550 VDC |
| Voltage range |
460 VDC ~ 900 VDC |
| MPP voltage range at full |
| ower |
625 VDC ~ 900 VDC |
| Number of MPP trackers / Maximum input current |
| Mains output (AC) |
| Nominal output |
230 VAC (P-N) / 400 VAC (P-P) |
| Output voltage range |
195.5 - 253 VAC per phase |
| Output frequency range |
49 ~ 51 Hz or 59.3 ~60.5 Hz |
| Nominal output current |
43. A per phase |
| Power factor |
| Efficiency |
| Maximum conversion efficiency (DC/AC) | 95% |
| Off-grid operation |
| AC input |
| AC starting voltage/automatic restart voltage |
150-170 VAC per phase / 180 VAC per phase |
| Acceptable input voltage range |
170-280 VAC per phase |
| Maximum AC input current |
43.5 A per phase |
| PV input (DC) |
| Maximum DC power/ Maximum DC voltage |
45 kW / 950 VDC |
| MPP voltage range |
460 VDC ~900 |
VDC |
| Number of MPP trackers/Maximum input current |
| A |
| Battery mode Output (AC) |
| Rated output voltage |
230 VAC (P-N)/400 VAC (P-P) |
| Output waveform |
Pure sine wave |
| Efficiency (DC to AC) | >91% |
| Hybrid operation |
| PV input (DC) |
| Rated DC voltage / Maximum DC voltage |
720 VDC / 950 VDC |
| Start-up voltage / Initial supply voltage |
500 |
V
DC / 550 VDC |
| MPP voltage range |
460 VDC ~ 900 VDC |
| Number of MPP trackers / Maximum input current |
| Mains output (AC) |
| Rated output voltage |
230 VAC (P-N) / 400 VAC (P-P) |
| Output voltage range |
195.5 - 253 VAC per phase |
| Output frequency range |
49 ~ 51 Hz or 59.3 ~60.5 Hz |
| Nominal output current | 43.5 per phase |
| Power factor |
| AC input |
| AC starting voltage/restarting voltage |
150 - |
170 VAC per phase / 180 VAC per phase |
| Acceptable input voltage range |
170 - 280 VAC per phase |
| Maximum AC input current |
43.5 A per phase |
| Battery mode output (AC) |
| Rated output voltage |
230VAC (P-N) / 400 VAC (P-P) |
| Efficiency (DC to AC) | >91% |
| Battery and charger |
| Nominal battery voltage/charging voltage range |
384 VDC / 384 VDC ~480 VDC |
| Maximum charging current | 80A |
| General |
| Physics |
| Dimension, | |
| DxWxH (mm) | 430x715x1021 |
| Net weight (kgs) | 223 |
| Interface |
| Communication port | RS-233/USB |
| Smart |
Optional SNMP, GPRS, WiFi, |
odbus cards available |
| Environment |
| Humidity |
~ 90% RH (non-condensing) |
| Operating temperature |
| to 55°C |
| Altitude |
| ~ 1000 m |
