Longi Solar Panel 400 Wp Hi-MO 5m

€72.60
Tax included
LR5-54HPB
0768563818653
  • High power
  • Half-cut cell
  • Module efficiency up to 21.5%
  • Higher energy efficiency with lower operating temperature
  • 12-year product warranty on materials
  • 25-year linear power warranty

3 item(s) left in Stock!

Longi 400 Hi-MO 5m

LONGi's high-efficiency PV modules are widely used around the world, from alpine meadows to desert wastelands, and from ponds and vegetable gardens to homes. LONGi's ultra-high-value PV module products continue to benefit customers and the local economy with its advantages of "superior power, lower degradation and superior reliability".

  • Advanced module technology delivers superior performance
  • MlO gallium-doped silicon wafer - Integrated segmented ribbons - Semi-cut 9-busbar cell
  • Excellent outdoor power generation performance
  • Aesthetic appearance with all-black module design

Intelligent soldering
Uniform intelligent soldering increases module power and efficiency, and improves electrical load capacity.

Optimized module size
M10 wafer and 54 cell design, taking full account of module size and weight in distributed applications.

Intelligent module packaging and logistics
Intelligent module packaging solutions are used to achieve high reliability, low-cost transport and logistics.

Optimized electrical parameters
Working current is around 13A, perfectly suited to consumer string inverters.

Gallium-doped technology
Gallium-doped technology overcomes LID degradation and guarantees the module's long-term energy production.

Benefits

  • High power
  • Half-cut cell
  • Module efficiency up to 21.5%
  • Higher energy efficiency with lower operating temperature
  • 12-year product warranty on materials
  • 25-year linear power warranty

Dimensions

Longi 400W


Features

Mechanical Parameters
Cell Orientation 108 (6 x 18)
Junction Box IP68, Three diodes
Output Cable 4mm²
Glass Single glass, 3.2 mm tempered coated glass
Frame Anodized aluminum alloy frame
Weight 20.8 kg
Dimension 1722 x 1134 x 30
Electrical Characteristics
Maximum Power (Pmax/W) 400
Open-Circuit Voltage (Voc/V) 36.9
Short-Circuit Current (Isc/A) 13.72
Voltage at Maximum Power (Vmp/V) 30.94
Current at Maximum Power (Imp/A) 12.93
Module Efficiency (%) 20.5
Operating Parameters
Operating Temperature -40°C ~ +85°C
Output Power Tolerance 0 ~ 3%
Maximum Series Fuse Rating 25 A
Nominal Operating Cell Temperature 48 ± 2°C
Protection Class Class II
Mechanical Load
Maximum Static Load on Front Side 5400 Pa
Maximum Static Load on Back Side 2400 Pa
LR5-54HPB

Data sheet

Max. power - Wp
400
Open circuit voltage (Voc)
36,90 V
Short-circuit current (Isc)
13,72 A
Max. power voltage (Vmp)
30,94 V
Max. power current (Imp)
12,93 A
Color
Full Black
Panel type
Rigids
Cells
Monocrystalline
Width
1134 mm
Height
1722 mm
Frame
30 mm
Weight
20,8 kg

Specific References

UPC
768563818653
EAN13
0768563818653
