Converter SRNE IC Series 12V - 2000W

€454.70

Tax included

Reference: SR-IC12-2kW

EAN13: 0768563820533

Rated power: 2000 W
Nominal battery voltage: 12 Vdc
Rated output voltage: 220 / 230 / 240 Vac
Output frequency: 50 / 60 Hz
Dimensions: 366 x 300 x 116 mm
Weight : 6 kg

100% secure payments

8 item(s) left in Stock!

SRNE IC Series

Yield

High conversion efficiency, low losses and low harmonic distortion are accompanied by a variety of operating modes designed to maximize energy savings.

Stable

Stable thanks to advanced SPWM modulation technology for high-quality, pure sinusoidal power output.

Connectivity

Bluetooth is integrated as a standard feature and is compatible with a mobile application, allowing you to view the device's operating parameters.

Security

Several extension interface options are available to meet different user requirements. The surge protection design is specifically optimized to suit lithium battery-powered supply systems.

Intelligent

Provides advanced protection for the battery against overvoltage and overdischarge, as well as preventing output overloads, short circuits and overheating.

Reference SR-IC12-2kW

In stock 8 Items

Data sheet

Frequency range: 50 / 60 Hz
Waveform: Onde sinusoidal pure
Battery voltage: 12 Vdc
Width: 300 mm
Height: 366 mm
Thickness: 116 mm
Standby consumption (night): + 0,24 A
Certification: CE, ROHS, IEC62109-1/2, EN61000-6-2/4
Typical noise level (dB): + 60 dB
Type of cooling: Neutral cooling + intelligent fan
THDi (Nominal power): THD +3%（Load resistance）
Battery Voltage Range: 10.8～16Vdc
Rated output power: 2000 W
Rated output voltage: 220 / 230 / 240 V
Peak power: 4000 W
Power factor: 0.2-1（Load power≤Continuous output power)
Nominal output: + 89 %
Max. output efficiency: +92% (30% load)
Ambient temperature: -20°C～60°C

Specific References

UPC: 768563820533
EAN13: 0768563820533

Condition New

Converter SRNE IC Series 12V - 2000W
