Deye 12 kVA single-phase hybrid inverter - SUN-12K-SG04LP3-EU
Deye 12 kVA single-phase hybrid inverter - SUN-12K-SG04LP3-EU
Deye 12 kVA single-phase hybrid inverter - SUN-12K-SG04LP3-EU

Deye 12 kVA three-phase hybrid inverter - SUN-12K-SG04LP3-EU

$3,015.7
SUN-12K-SG04LP3-EU
0768563821059

Your own power station

Maximize your energy autonomy with the Deye SUN-12K hybrid inverter.

Designed for individuals and small businesses, this intelligent inverter lets you generate, store and consume your own solar energy. It's ideal for reducing your dependence on the power grid and lowering your electricity bills.

Why choose Deye SUN-12K?

  • Maximum flexibility: Adapt to your evolving needs thanks to its many features.
  • Simplified installation: Quick and easy commissioning.
  • Intelligent management: Optimize your energy consumption thanks to remote monitoring.
  • Energy autonomy: Benefit from solar energy even in the event of a power cut.

Key benefits:

  • Storage: Conserve your solar energy.
  • Priority: Use your solar energy first.
  • Monitoring: Track your consumption live.
  • Installation: Plug and play, it's easy!

How does it work?

The Deye SUN-12K inverter converts the energy produced by your solar panels into usable alternating current. It can then charge a battery to store excess energy and release it when needed. Thanks to its intuitive interface, you can easily monitor and control your system.

Ready to make the leap to energy autonomy?

3 item(s) left in Stock!

Deye 12 kVA three-phase...

$3,015.7

Présentation onduleur DEYE



Deye SUN-12K-SG04LP3-EU Hybrid Inverter

Do you dream of an energy self-sufficient home? This solar inverter is the ideal solution for optimizing your solar energy production and reducing your dependence on the power grid. Thanks to its exceptional performance and versatility, it can be adapted to all your needs.



Concentrated technology for your energy needs



This solar inverter, the heart of your photovoltaic system, is designed to convert the energy produced by your solar panels into electricity that can be used in your home. Thanks to its advanced technical features, it guarantees optimum efficiency and rock-solid reliability.



  • Energy versatility: Compatible with lead-acid and lithium-ion batteries, it adapts to your specific needs and budget.
  • Maximum power: With a maximum PV input power of 15600W and an AC output power of 12000W, it meets the requirements of the most demanding installations.
  • Optimum efficiency: Its high conversion rate guarantees maximum use of the solar energy produced.
  • Installation flexibility: Adapts to all types of configuration, from the simplest to the most complex.
  • Reliability: Designed to operate in extreme conditions, it offers a long service life.



The benefits for you

  • Energy autonomy: Generate your own electricity and consume it independently.
  • Energy savings: Reduce your electricity bill considerably and invest in your future.
  • Respect for the environment: Reduce your carbon footprint and contribute to a more sustainable future.
  • Comfort and peace of mind: Benefit from a stable, reliable power supply, even in the event of a power cut.



Key technical features

  • Battery: Lead-acid or lithium-ion (40-60V)
  • Charge/discharge current: 240A
  • PV input power: Up to 15600W
  • PV input voltage: 800V maximum
  • AC output power: 12000W



Main Display



The LCD screen is touch-sensitive and displays general inverter information.



affichage onduleur

1 - The icon in the center of the home screen indicates that the system is operating normally. If it displays "comm./F01~F64", this means that the inverter has communication or other errors. The error message will be displayed below this icon (errors F01-F64, error details can be viewed in the System Alarms menu).

2 - At the top of the display is the time.

3 - System configuration icon. Press this button to access the system configuration screen, which includes basic configuration, battery configuration, network configuration, system operating mode, generator port usage, advanced functions and Li-Ion battery information.

4 - The main screen displays solar, network, load and battery information. It also indicates the direction of power flow by arrows. As power approaches a high level, the color of the panels changes from green to red, providing a clear view of system information on the main display.



- PV power and charging power always remain positive.

- Negative grid power means selling to the grid, positive means receiving from the grid.

- Negative battery power means charging, positive means discharging.




image illustrationRemote shutdown function



Intelligent monitoring platform

Thanks to the intelligent monitoring platform, inverter products in the Deye complete series support remote shutdown immediately in the event of an accident. Parameter settings and firmware updates can be performed remotely, facilitating the operation and maintenance of photovoltaic systems.




Technical data



- Compatibility and Battery Input

Compatible with lead-acid and lithium-ion batteries, automatically adapting to battery management systems (BMS). 48V battery voltage range.

- High efficiency

Maximum efficiency of 97.6%, European efficiency of 97% and MPPT efficiency in excess of 99%, guaranteeing maximum energy conversion and minimum losses.

- Nominal power

Models available from 5kW to 12kW (SUN-5K, SUN-8K, SUN-10K and SUN-12K), with peak power capacities up to twice the rated power for durations of 10 seconds.

- Advanced protection mechanisms

Includes comprehensive protection features: DC reverse polarity protection, AC output overcurrents, AC output overvoltages, thermal protection and ground fault protection.

- Standards compliance

Meets numerous international safety and performance standards, including IEEE 1547.1, EN 62109-1/2 and UL 1741.

- Operating range

Works well over a wide temperature range (-40°C to +60°C) and can operate at altitudes of up to 2000 meters, maintaining noise levels below 30dB.

- Monitoring and communication

Supports various monitoring and communication interfaces, including GPRS, WIFI, Bluetooth, 4G and LAN. RS485, RS232 and CAN communication interfaces for robust connectivity and flexible integration.




Physical specifications



- Dimensions

Measures 422 mm × 658 mm × 254 mm, compact and easy to install.

- Weight

Weighs 38kg, for easy handling and installation.

- Cooling

Intelligent air cooling for efficient thermal management.

- Protection class

IP65 protection, suitable for various indoor and outdoor installations.




UPS operation with Pylontech batteries


Warranty & Support



Warranty

5-year or 10-year warranty, offering peace of mind and assurance of reliability. Warranty period may vary according to installation site and applicable terms.




The DeyeSUN SUN-12K-SG04LP3-EU hybrid inverter is a powerful and flexible solution for optimized energy management. With high efficiency, comprehensive protection and advanced control features, it's perfect for your energy storage and solar application needs. Its intelligent design and robust features make it an excellent choice for modern energy needs.

SUN-12K-SG04LP3-EU

Data sheet

Max.PV Input Power
15600 W
Width
422 mm
Height
658 mm
Thickness
254 mm
Max. load current
240 A
Starting voltage
160 V
Rated mains frequency
50/45-55, 60/55-65 HZ
Standard warranty (years)
5 years/10 years, the warranty period depends on the final installation site of the inverter. For more information, please refer to the warranty policy.
Humidity
0 à 100 %
Euro. Efficiency
97,0 %
Maximum discharge current
240 A
Battery Type
Lithium-ion & lead-acid
Battery Voltage Range
40 ~ 60 V
Weight
38 kg
Maximum input short-circuit current
34+17 A
Peak power
2 times rated power, 10 S (off-grid)
Maximum operating altitude
2000 m
Noise
less than or equal to 55 dB
Max. PV input voltage
800 V
Number of MPP trackers / strings per MPP tracker
2(1/1)
MPPT voltage range
200-650 V
PV input current
26 + 13 A
DC injection current
less than 0.5%
Charging strategy for Li-Ion batteries
Self-tuning to BMS
Interface/communication
TS485/RS232/CAN
Rated PV input voltage
550 V
Rated AC input/output active power
12000 W
Maximum apparent AC input/output power
13200 VA
Rated AC input/output current
18,2/17,4 A
AC input/output current
20/19.1 A
Maximum continuous power (from mains to load)
45 A
Power factor adjustment range
0.8 upstream to 0.8 downstream
Form of network connection
3L + N + PE
Total harmonic current distortion THDi
less than 3% (of rated power)
Maximum yield
97,6 %
MPPT efficiency
More than 99
Monitoring mode
GPRS/WIFI/Bluetooth/4G/LAN (en option)

Specific References

New

Download

DataSh Inverter Deye-SG04LP3-EU

Download (382.94KB)
