Three-phase inverter Sofar Solar 30KTLX-G3
Three-phase inverter Sofar Solar 30KTLX-G3

Three-phase inverter Sofar Solar 50KTLX-G3

€2,271.10
Tax included
Sofar-50KTLX-G3
0768563820069

Sofar Solar 50 kVA Three-Phase Inverter: Optimize Solar Energy Production for Your Commercial Installations

The Sofar Solar 50 kVA 50KTLX-G3 inverter is designed to optimize the solar energy production of your commercial installations. With its three MPPT trackers and exceptional efficiency of 98.9%, it effectively converts solar energy into usable electricity, meeting the energy needs of your professional buildings.

Why Choose the Sofar Solar 50 kVA Inverter?

  • Maximum Efficiency: Thanks to a high-performance MPPT algorithm, this inverter captures the maximum amount of solar energy, optimizing your production.
  • Flexibility: Adapts to different solar panel configurations and can be connected to networks of various sizes.
  • Reliability and Durability: It offers long life and stable performance.
  • Smart Monitoring: Track the performance of your system in real time with the dedicated app.

Key Advantages:

  • Maximize your self-consumption and reduce your energy bills.
  • Easy installation with an intuitive design.
  • Optimal protection against surges.
  • Intelligent management of your energy production.

Sofar Solar 50 kVA: A Reliable Investment for Professional Solar Energy.

Sorry, there are no more items in stock.

Comments (0)

No customer reviews for the moment.

Inverter Sofar Solar 50 kVA : Maximise your solar production with 3 MPPT

New G3 three-phase inverter for small commercial PV installations

The SOFAR 25K-30KTLX-G3 inverter series is the upgraded version of SOFARSOLAR's C&I three-phase inverter series. The 3rd generation version is equipped with up to three MPPTs and features nine different power classes to meet the demands of medium-sized PV installations.

The inverter features 4 digital input ports and one CT input port for power control, enabling easy configuration to meet grid codes in many countries. For additional protection, the inverter is equipped with integrated type II surge arresters on the DC and AC sides.

A WiFi stick is supplied with the inverter, for easy connection to the SOFAR View monitoring portal.

High efficiency

- Maximum efficiency of 98.9%.
- Precise real-time MPPT algorithm for maximum utilization
- Wide input voltage operating range

All in one. Flexible, cost-effective system solution

- Free choice of location thanks to IP65 rating
- LCD + LED display
- Integrated zero export function (optional)

Low maintenance costs

- Detachable lid for easy installation
- Stainless aluminum covers
- A flexible control solution

Intelligent grid management

- Reactive power capacity
- Automatic power reduction in the event of overfrequency
- Remote control of active/reactive power limit

Features

DC INPUT
PV input power max.
Recommended 75000 Wp
Max. power.
DC power per MPPT 25000 W
Number of MPP trackers
Number of DC inputs
for each MPPT
Max. input voltage 1100
Starting voltage 200 V
Nominal input voltage 620 V
MPPT operating voltage range 180 - 1000 V
Full MPPT power in voltage range 540 - 850 V
Max. MPPT input current
x 40 A
Max. input short-circuit current.
By MPPT
x 50 A
AC output
Rated power 50000 W
Max. power.
In AC 55000 VA
Max. output current 83.3
A
Mains voltage
/ N / PE,
230 / 400 Vac
Mains voltage range 310 -
480 Vac (depending on local standards)
Nominal mains frequency 50 Hz / 60 Hz
Mains frequency range 45 - 55 Hz / 55 - 65 Hz (depending on local standards)
Adjustable active power range
- 100%
THDi <
3%
Power factor
default (adjustable +/-0.8)
PERFORMANCE
Max. efficiency 98,80%
Weighted European efficiency 98.20%
PROTECTION
Protection against reverse polarity in DC Yes
Anti-reverse power function and DC switch Optional
Safety protection
Anti-islanding protection,
leakage current protection, ground fault monitoring, PV array line fault monitoring, reverse power limiting,
Lightning arrester input/output PV:
Type II standard, AC: Type II standard
COMMUNICATION
Standard communication mode RS485 / Wi-Fi / Bluetooth
Optional :
Ethernet
GENERAL
Ambient temperature range
30°C to 60°C
Night-time power consumption <3 W
Topology Transformerless
Degree of protection IP65
Permissible relative humidity range
- 100%
Max. altitude.
Operating
4000 m
<
60 dB
Weight 37 kg
Cooling Fan
Dimensions
x 480 x 220 mm
Display LCD, App via Bluetooth
Warranty 10 years
Standards
(electro-magnetic compatibility) EN 61000-6-1, EN 61000-6-2, EN 61000-6-3,
EN 61000-6-4
Safety standards IEC 62109-1/2, IEC 62116, IEC 61727, IEC 61683, IEC 60068 (1,2,14,30),
IEC 60255
Network standards
V 0124-100, V 0126-1-1, VDE-AR-N 4105, CEI 0-21 / CEI 0-16, UNE 206 007-1, EN 50549, G98 / G99, EN 50530
Sofar-50KTLX-G3

Data sheet

Inverter power
50000 VA
MPPT/PWM
MPPT
Phase
Triphasé
Number of MPPT
3 MPPT
Video Youtube 1 - ID
rve7GWSFV3Q

Specific References

UPC
768563820069
EAN13
0768563820069
