    $1,831.1
    1405-00
    0712971126534
    • Ultralight outboard
    • Equivalent to 1 CV
    • High capacity lithium battery
    • Tough
    • With charger, remote control lever, on-board computer, GPS calculation of the remaining distance and circuit breaker magnetic key
    • Steering / Lifting / Automatic Lifting – Easy integration with the rudder of the kayak.
    • Extended navigation functions of the on-board computer with the Optional TorqTrac app
    • New angler stand with tilt and parking mechanism, plus simple integration with the kayak steering unit
    Ultralight: Ultralight 403 A

    Torqeedo Ultralight Engine

    $1,831.1

    Torqeedo Ultralight 403A - 403AC - 1103AC



    Torqeedo Ultralight 403A



    The new ultralight 1 HP engine, a favorite of professional fishermen, takes you to the best bottom and leaves you with your hands free to catch the fish. Torqeedo engineers have equipped this new model with a new fastening system that mounts on the back of any fishing kayak. The Ultralight equipped with this robust, practical and universal fastener, offers a great autonomy to be able to fish longer. In addition, the support is much simpler to assemble and handle, and is quickly disassembled and stored.
    Fishing enthusiasts have the choice between two batteries of 320 or 915 Wh depending on their needs and the type of kayak.



    Ultralight 403 A – The advantages:

    • Total weight 8.8 kg with battery
    • Built-in 320 Wh high capacity lithium battery
    • Range of 35 km at low revs (also depending on the type of boat)
    • Fully waterproof (IP67)
    • Accurate calculation of the remaining distance by GPS
    • Solar charging, also along the way



    Ultralight 403 AC – The advantages:

    • Total weight 11.0 kg with battery
    • Built-in 915 Wh high capacity lithium battery
    • Range of 100 km at low revs (also depending on the type of boat)
    • Fully waterproof (IP67)
    • Accurate calculation of the remaining distance by GPS
    • Solar charging, also along the way



    Ultralight 1103 AC – The advantages:

    • Total weight 15.3 kg with battery
    • Built-in 915 Wh high capacity lithium battery
    • Range of 50 km at low revs (also depending on the type of boat)
    • Fully waterproof (IP67)
    • Accurate calculation of the remaining distance by GPS
    • Solar charging, also along the way



    IMG 2 - Torqeedo



    Autonomy



    Ultralight 403 A with built-in battery (320 Wh / 29.6 V / 11 Ah)

     Speed in km/h*Range in km*Autonomy in hours
    Low revs4,2358:20 AM
    Mid-diet6254h10
    Full throttle9,37,512:48 AM
    * Depending on the type of boat, load, propeller and environmental protection conditions. Speeds and ranges indicated subject to all reservations.



    Ultralight 403 AC with built-in battery (915 Wh / 29.6 V / 31 Ah)

     Speed in km/h*Range in km*Autonomy in hours
    Low revs4,210124h00
    Mid-diet67111:50 a.m.
    Full throttle9,321,72:20 AM
    * Depending on the type of boat, load, propeller and environmental protection conditions. Speeds and ranges indicated subject to all reservations.



    Ultralight 1103 AC with built-in battery (915 Wh / 29.6 V / 31 Ah)

     Speed in km/h*Range in km*Autonomy in hours
    Low revs5,853,309:11
    Mid-diet10,915,91:28 AM
    Full throttle12,510,412:48 AM
    * Depending on the type of boat, load, propeller and environmental protection conditions. Speeds and ranges indicated subject to all reservations.



    Autonomy and speed - Notes
    In Archimedean mode, the required engine power rises to the speed of power three, i.e. to double its speed on the water, it is necessary to multiply the power by eight.
    In return, it is enough to slightly reduce the speed to increase the autonomy significantly.
    The Ultralight's on-board computer continuously calculates the remaining range from the engine consumption parameters, battery state of charge and background speed transmitted by GPS, and displays the remaining remote in real time on the engine screen and on the TorqTrac app for Smartphones.


    Characteristics



    ModelUltralight 403 AUltralight 403 ACUltralight 1103 AC
    Input power in watts4001100
    Propulsion power in watts180540
    Equivalent to a thermal outboard of (propulsion power)1 CV3 HP
    Equivalent to a thermal outboard of (thrust)2 CV
    Maximum overall return in %4549
    Static thrust in lbs*33
    Built-in battery320 Wh Li-Ion915 Wh Li-Ion
    Rated voltage in volts29,6
    Final charging voltage in volts33,6
    Total weight in kg8,81115,3
    Motor weight without battery in kg59,3
    Built-in battery weight in kg3,86
    Tree length in cm4851
    Standard propeller
    (v = speed in km/h for power p in watts)
    v10/p350Spare propeller v10/p1100 anti-algae
    Propeller instruction
    Maximum propeller speed at full rpm12001450
    OrderJoysticks
    TorqLinkNo
    DirectionRudder plug of the kayak; blockable steering
    LiftingManual + auto in case of stranding
    TrimManual, 4 positions
    Continuous AV/AR accelerationYes
    Built-in on-board computerYes
