    Epever IPower 12V 500VA inverter

    $138.0
    IP-1000
    0768563818332

    - Pure sine wave inverter DC 12V AC220V 500VA

    Epever IPower IP1000: Epever IPower 12V

    5 item(s) left in Stock!

    Epever IPower 12V 500VA...

    $138.0

    Epever IPower 12V 500VA inverter

    The IPower series is a pure sine-wave converter that can be converted.
    The industrial design, compared to the civil design, allows for wider temperature operation, easy installation and operation.
    The wide input voltage range is ideal for solar system applications.
    The inverter can be applied in many fields, such as home emergency lighting systems, vehicle-mounted systems and small-field power supplies, etc.


    Specifications

    • Safe design with electrical isolation of input and output
    • Adoption of advanced SPWM technology, pure sine wave output
    • Optional output voltage 220/230VAC (or 110/120VAC), selectable via DIP switch
    • LED indicators for fault status and operating status
    • Reduced no-load consumption
    • Maximum efficiency up to 95%
    • Input protection :
    • Overvoltage protection, low-voltage protection
    • Output protection:
    • Overload protection, short-circuit protection
    • Overtemperature protection: Ventilation by temperature-controlled fan;
    • Inverter shuts down automatically in the event of overtemperature
    • USB output operational 5VDC/1A
    • RS485 communication operational port

    Features

    ModelIP500-12
    Nominal input voltage12VDC
    Input voltage range10.8 ~ 16VDC
    Input surge voltage<32VDC
    Output voltage220VAC / 230VAC (± 5%)
    Output frequency50/60±0.1Hz
    Continuous output power400 W
    Output power 15 min.500
    W
    Surge power1000 W
    Power factor
    .2-1 (VA less than continuous output power)
    Onde de sortie Pure sine wave
    Distorsion THDTHD≤3%
    Max.
    Efficiency92%
    No-load current<0.9A
    USB output port
    .1A
    Link stationΦ6mm
    Overall dimension (mm)232.2 x 132 x 74.5 mm
    Mounting dimension205 x 102 mm
    Size of mounting holesΦ5.2mm
    Net weight
    .7 kg
    IP-1000

    Data sheet

    Voltage
    12V
    Power
    500 VA
