Self-consumption Kit 72 panels 20kVA storage and Reinjection

Wattuneed

37 852,35 € tax incl.

Add to cart

Self-consumption Kit with ready-to-use storage of 72 panels

This complete kit includes basic :

  • 72 panels TrinaSolar 265Wc
  • 2 inverters MultiSolar 10kVA 48V
  • Double insulated solar cable 4mm ²
  • 1 120kWH OPzS Battery Park

Optional:

  • Mounting system.
  • Electrical protection
  • Auxiliary power supply system (wind turbine/generator)

This kit is ideal for a sustained consumption or a large household.

All our kits are changeable, thanks to this system no error is possible and we check each kit before sending. Test our configurator right now!

More details
