    Solar controller MPPT SRNE 48V 60A - ML4860

    $254.8
    ML4860
    0712971136731

    The new SRNE range of solar controllers offers optimum MPPT tracking efficiency of 99.9%, as well as load efficiency 15-20% higher than PWM.

    6 item(s) left in Stock!

    Solar controller MPPT SRNE...

    $254.8

    SRNE MPPT 48V 60A

    Advanced double-peak or multi-peak tracking technology. When the panel has a shadow block or part of the panel is damaged, the I-V curve shows several peaks. The solar charge controller can always accurately track the maximum power point.

    Integrated algorithm for maximum power tracking. This significantly increases the energy utilization efficiency of photovoltaic systems, with charge efficiency 15% to 20% higher than traditional PWM solar charge controllers.

    A combination of multiple tracking algorithms enables precise tracking of the optimal working point of the I-V curve in a very short time.

    MPPT tracking efficiency up to 99.9%.

    SRNE 48V 60A

    Advanced digital power supply technology, with circuit energy conversion efficiency as high as 98%.

    Supports charging procedures for gel batteries, sealed batteries, open batteries, lithium batteries and other battery types.

    Current-limiting charging mode. When the power of a solar panel is too high and the charging current exceeds the rated current, the solar charge controller automatically reduces the charge, so that the solar panel operates at the rated charging current.

    Supports instantaneous capacitive load current start-up.

    Supports automatic battery voltage identification.

    LED malfunction indicator, audible alarm and LCD display of abnormal information. This helps users to identify system faults.

    Historical data storage for up to 5 years.

    LCD display function. The display allows users to view data and equipment operating status, and modify controller parameters at the same time.

    Support for standard Modbus protocol to meet communication needs on different occasions.

    Integrated overheating protection mechanism. When the temperature exceeds the preset value, the load current falls linearly with the temperature, slowing down the temperature rise of the controller and preventing damage to the controller at high temperatures.

    External battery voltage sampling function. This function prevents line loss from affecting external battery voltage sampling and ensures greater accuracy of control parameters.

    Temperature compensation functions. Charging and discharging parameters are automatically adjusted, extending battery life.

    TVS light protection.

    Model4860
    System voltage12V/24V/36V/48V Auto
    0
    No-load loss
    .7 W ~ 1.2W
    9V
    Battery voltage
    ~ 70V
    Maximum solar power input voltage<150V
    Maximum power voltageBattery voltage +2V ~ 120V
    Charging current60A
    Rated current20A
    Capacitive charging capacity
    max.10000uF
    Photovoltaic system Max. input power

    800W/12V
    1600W/24V
    2400W/36V
    3200W/48V

    Conversion efficiency≤98%
    MPPT tracking efficiency>99%
    Temperature compensation coefficient-3mv/℃/2V (default)
    -35℃
    Operating temperature
    ~ +45°C
    Protection levelIP32
    3
    Weight
    .6Kg
    Max. wiring size25 mm²
    Communication modeRS485, RS232
    Altitude≤ 3000m
    Product size285*205*93mm

    ML4860

    Data sheet

    Charging power
    60A
    Voltage
    48V
    MPPT/PWM
    MPPT
    Video Youtube 1 - ID
    GXvxzPA7aBI
    Video Youtube 2 - ID
    3d6UxdYAD5U

    Specific References

    New

    Download

    Manual SRNE-ML48/60-EN

    Download (1.47MB)

    Manuel SRNE-ML48/60-FR

    Download (1.53MB)
