Hybrid inverter 15kW injection network - Multisolar storage

Wattuneed

5 187,87 € tax incl.

- AC output power: 15000W
- AC Pure Sinus Release
- Controlled by microprocessor
- Independent MPPT Trackers: 2
- Backlit LCD screen



More details

More info

Hybrid inverter 15kW injection network - Multisolar storageMultiSolar: Store the bare minimum in your batteries and re-inject the bare minimum into the network, provided the batteries are full.

On the other hand, use the network to fill the gap winter production and make a little extra on the batteries when the rainy days follow.

Make the most of your production and no longer fear any power outages.

Plug in until 14850Wc at the PV entrance of the 'linkpopup id'onduleurHybride'

Store and use your solar-generated electricity later.



Production curve


Hybrid inverter 15kW injection network - Multisolar storagedescription



High-performance MultiSolar inverter -linkpopup id'triphase' to manage a hybrid electrical installation.

Connect solar panels, batteries, and optional network input to power your facility

Enjoy the best performance with two built-in independent 'linkpopup id'mppt' trackers, as well as a comfortable use of its compact design and intuitive LCD screen.

  • Pure sinusoidal signal output: 10kW
  • Maximum PV input power: 14850Wc
  • AC Entry: 'linkpopup id'triphase'
  • AC release: 'linkpopup id'triphase'
  • Controlled by microprocessor for stability
  • Multiple operations: Connected to the network, off-grid and connected to the network with backup power
  • Built-in solair charger (two independent inputs)
  • Backlit LCD screen for simple, interactive use
  • Multiple means of communication
  • "Green" alternative to generators
  • User-adjusted battery charge intensity, up to 200A





Remote control and inverter configuration



Connect the inverter to your computer with the USB cable provided.

SolarPower software allows the control and tracking of multiple devices via the local network, internet or USB.

Alert notifications, pop-up screen, text messages and email.



Parameter settings


Characteristics



phase3 phase in / 3 phase out
Max PV power22500 W
Power on the way out15000 W
Max charge power15000 W
Network-connected operation
Solar Entrance (DC)
Rated DC Tension / Maximum DC Tension.720 VDC / 900 VDC
Start-up tension / Work min tension320 VDC / 350 VDC
MPP voltage range400 VDC - 800 VDC
Entry number MPP/maximum current input2/A: 37.65A; B:18.6A
Consumer output (AC)
Nominal output voltage230 VAC (N-P)/400 VAC (P-P)
Exit voltage range184 - 264.5 VAC per phase
Nominal output current21.7 A per phase
Power factor> 0.99
yield
Maximum conversion return (DC/AC)96,00%
European performance at the tension 95,00%
Off-grid
AC Entry
AC start voltage /automatic restart voltage120 - 140 VAC per phase
180 VAC per phase
Entry voltage range170 - 280 VAC per phase
AC max input current.40 A
Solar Entrance (DC)
Tension DC max.900 VDC
MPP voltage range350 VDC - 850 VDC
Entry number MPP/maximum current input2/A: 37.65A; B:18.6A
Battery mode (AC) release
Nominal output voltage230 VAC (N-P)/400 VAC (P-P)
Signal shapePure sinus
yield (DC/AC)91,00%
Hybrid operation
Solar Entrance (DC)
Rated DC Tension / Maximum DC Tension.720 VDC / 900 VDC
Start-up tension / Work min tension320 VDC / 350 VDC
MPP voltage range350 VDC - 850 VDC
Entry number MPP/maximum current input2/A: 37.65A; B:18.6A
Consumer output (AC)
Nominal output voltage230 VAC (N-P)/400 VAC (P-P)
MPP voltage range184 - 264.5 VAC per phase
Nominal output current21.7 A per phase
AC Entry
Start-up tension / Work min tension120 - 140 VAC per phase
180 VAC per phase
Entry voltage range170 - 280 VAC per phase
AC max input current.40 A
Battery mode (AC) release
Nominal output voltage230 VAC (N-P)/400 VAC (P-P)
yield (DC/AC)91,00%
Batteries and charger
Nominal DC tension48 VDC
Max charge current.Default 60A, 5A -300A (adjustable)
General features
Physical characteristics
Dimensions P x L x H219 x 650 x 820 mm
weight62 Kg
interface
Communication portRS-232 / USB and CAN Interface
Intelligent SlotOptional SNMP, Modbus and AS-400 cards
environment0 - 90% HR (without condensation)
humidity-10 to 55 degrees Celsius
Working temperature0 - 1000m

Specifications

Weight62 kg
Monophasé / TriphaséTriphasé
Nombre de MPPT2 MPPT
Width500 mm
Height622 mm
Thickness176 mm
Inverter power15000VA
