Avasco SolarSpeed configuration south portrait 3.0

Avasco SolarSpeed configuration south portrait 3.0

$130.4

Reference: Avasco Solar SolarSpeed3.0

EAN13: 0768563819803

Avasco SolarSpeed mounting system portrait 3.0 south configuration

Mounting system sold WITH clamps!

Description
Product Details

Présentation du système de fixation Avasco

Point distances

Optimum combination of shadow formation (tilt distance) and efficiency (angle): 10°-2500 mm

Compatible with any solar panel

SolarSpeed base units can be used for 60- and 72-cell panels.

Ultra-fast assembly

The "fit&click" frame is easy to fit together, guaranteeing simple installation and short assembly times.

Pre-assembled base units

The use of pre-assembled base units not only saves installation time, but also considerably reduces the number of individual parts on the roof!

Made of zinc-magnesium steel

Zinc-magnesium steel, with its robust, self-healing properties, is perfectly suited to applications with stringent requirements for long-term corrosion resistance.

Mounting system details

* Mounting system sold WITH clamps!

Contenu du kit de fixation
Nombre de panneaux	Equerre Portrait - 2500 mm - 10°	Renfort pour equerre	Backplate Portrait Equerre 10° - 1140mm	Support cornière 40mm	Cornière de lestage /Portrait 1200mm	Caoutchoucs de début de ligne	Chevilles pour fixation caoutchoucs	Vis autoforante	Clame de fin	Clame de milieu
1 panneau	2	2	1	1	2	2	4	100	4	0
2 panneaux	3	3	5	3	6	3	6	100	4	2
3 panneaux	4	4	9	5	10	4	8	100	4	4
4 panneaux	5	5	13	7	14	5	10	100	4	6
5 panneaux	6	6	17	9	18	6	12	100	4	8
6 panneaux	7	7	21	11	22	7	14	100	4	10
7 panneaux	8	8	25	13	26	8	16	100	4	12
8 panneaux	9	9	29	15	30	9	18	100	4	14
9 panneaux	10	10	31	17	34	10	20	100	4	16
10 panneaux	11	11	35	19	38	11	22	100	4	18

Reference Avasco Solar SolarSpeed3.0

Data sheet

Mounting: Flat roof - floor structure

Specific References

Condition New
