Hybrid inverter WKS-MLV 6kVA 48V

WKS

1 376,34 € tax incl.

Inverter designed for 120Vac AC networks.

This model can only work with a 120Vac AC network system that suits America.

If you want this specific model, you can contact us by chat, email or phone.

More details

More info

WKS-MLV 6kVa 48V

  • Pure sine wave inverter

  • Built-in MPPT solar charging regulator

  • Selectable entry voltage range for household appliances and personal computers

  • Application-selectable load current

  • AC/Solar input priority configurable via LCD screen setting

  • Compatible with network voltage or generator power

  • Automatic restart during KT recovery

  • Protection from overloads and short circuits

  • Smart battery charger design to optimize battery performance

  • Cold start function

  • Solar inverter


Description of the function of the icons



Indicates that the unit is connected to the sectorIndicates that the unit is connected to the sector





Indicates that the unit is connected to the photovoltaic panelIndicates that the unit is connected to the photovoltaic panel





 Indicates that the load is provided by the sectorIndicates that the load is provided by the sector



Indicates that the sector loader circuit is workingIndicates that the sector loader circuit is working





Indicates that the solar charger circuit is working Indicates that the solar charger circuit is working





Indicates that the CC/CA inverter circuit worksIndicates that the CC/CA inverter circuit works





 Indicates that the unit alarm is disabledIndicates that the unit alarm is disabled





Indicates that Bluetooth is connected Indicates that Bluetooth is connected





Time view pageTime view page






Characteristics



Type 120/240V Split phase,
120V Single phase,
120V/208V Split phase
Capacity6000VA/6000W
ParallelYES. 3 units
Parallel Kit Part NO. N/A
Battery Voltage48Vdc
Number of MPP Trackers 2
MPPT SCC8000W(4000W*2)
Vmp Range60~115Vdc
Voc145Vdc
Max. Solar Charger160A
Max. AC Charger60A
Max. Charger220A
Transfer Time10/20ms
12V DC PowerN/A
LCD2.8" green LCD
RGB LightsN/A
Wifi module with APPN/A
RS485 BMS portN/A
BMS YES, optional BMS Modbox box
Battery IndependencyN/A
USB On-the GoN/A
Remote panelN/A
Dimension, DXWXH(mm)130x622.6x610
Weight30 kg
Safety RegulationN/A
EMCN/A
Grid RegulationN/A
Battery TypeLead-acid or Lithium-ion
IP Rating IP20

Specifications

Voltage48V
MPPT/PWMMPPT
Weight30 kg
Monophasé / TriphaséMonophasé
Width622,6 mm
Height610 mm
Thickness130 mm
Inverter power6000VA
