Samsung RAC Luzon heat pump of 2.5 and 6.5 kW
€1,470.63
Tax included
LUZON-09-12-18-24
0768563817939
The Samsung Wind Free heat pump is available from 2.5 to 6.5 kW provided cleaner, healthier air while eliminating drafts thanks to its micro-perforated design. It provides rapid heating or cooling and consumes little energy.
Please choose your model opposite.
Sorry, there are no more items in stock.
Stay cool comfortably with Wind-Free™ technology.
Designed to cool faster, wider and farther
Quick cooling
Cool the pieces quickly from one corner to the other, so you're always comfortable. Digital Inverter Boost technology cools the air 43% faster. Its advanced design also has a 15% larger fan, an 18% wider input and a 31% wider blade. The fresh air is scattered further and wider, reaching up to 15 meters.
Simply cleans up - automatically
Automatic cleaning
When the air conditioner is turned off, Auto Clean automatically operates a fan to remove dust and moisture from the heat exchanger. It therefore remains clean and dry, which prevents the growth of bacteria and mildew.
Easy-to-clean antibacterial filter
Easy Filter Plus
Make your air conditioner work efficiently with less effort. The Easy Filter Plus is located outside, on top, so it can be easily removed and cleaned. Its dense mesh keeps the heat exchanger clean and an antibacterial coating protects you from dangerous air contaminants.
Prevents corrosion for long-lasting cooling
DuraFin ™ More
Stay comfortably cool for longer. The Ocean Fin is made of a corrosion-resistant material to protect the condenser from rust, which helps maintain the optimal performance of the heat exchanger. Its superb corrosion resistance has been proven by using the salt mist (SST) test for 480 hours.
Ecological chiller
Refrigerant R32
Protecting the planet by reducing the impact of climate change. The air conditioner uses the next-generation R32 refrigerant, which helps conserve the ozone layer and has a low impact on global warming compared to conventional R22 or R410A refrigerants. So it's much greener.
Saves energy and money, cools efficiently
Ecological mode
Save energy, but stay cool. ECO mode uses less compressor capacity than Normal mode, which reduces energy consumption. It allows you to cool down more efficiently when it's not too hot outdoors or save energy and money at all times, so you don't have to worry about electricity bills.
Sleep much better all night
Good sleep
Good sleep mode creates the perfect climate for a good night's sleep. Thanks to its temperature control, it keeps you at ease, so you fall asleep quickly, sleep soundly and wake up fresh.
Characteristics
| Kit name | LUZON 09 | LUZON 12 | LUZON 18 | LUZON 24 | ||
| Inner unit | AR09TXHZAWKNEU | AR12TXHZAWKNEU | AR18TXHZAWKNEU | AR24TXHZAWKNEU | ||
| Outdoor unit | AR09TXHZAWKXEU | AR12TXHZAWKXEU | AR18TXHZAWKXEU | AR24TXHZAWKXEU | ||
| Ability | ||||||
| Ability | Cooling (nominal) | Kw | 2.5 | 3.5 | 5.0 | 6.5 |
| Cooling (Min-Max) | Kw | 0.9-3.4 | 0.9-4.0 | 1.6-6.7 | 1.4-7.6 | |
| Heating up -7 degrees Celsius | Kw | 3.2 | 3.5 | 6.0 | 7.4 | |
| Heating (Min-Max) | Kw | 0.9-4.5 | 0.9-5.0 | 1.3-8.0 | 1.2-9.4 | |
| Heating up --5C | Kw | 2.74 | 03:09 | 4.84 | 6.00 | |
| Heating - 10 degrees Celsius | Kw | 02:48 | 2.87 | 4.57 | 5.55 | |
| Heating - 15 degrees Celsius | Kw | 2.29 | 2.58 | 4.58 | 5.66 | |
| Benefit | ||||||
| Energy-efficient cooling | SEER | W/W | 6.7/A | 6.5/A | 6.8/A | 6.4/A |
| Energy consumption | kWh/a | 131 | 188 | 257 | 355 | |
| Pdesignc | Kw | 2.5 | 3.5 | 5.0 | 6.5 | |
| Era | W/W | 3.57 | 2.87 | 3.60 | 3.33 | |
| Energy-efficient heating | Scop | W/W | 4.0/A | 4.0/A | 3.8/A | 4.0/A |
| Energy consumption | kWh/a | 735 | 770 | 1400 | 1.511 | |
| Pdesignh (medium) | Kw | 2.1 | 2.2 | 3.8 | 4.1 | |
| Cop | W/W | 3.81 | 3.72 | 3.51 | 3.15 | |
| Dehumidification | L/h | 1.0 | 1.5 | 2.0 | 2.5 | |
| Maximum air volume (cooling) | Inner unit | m3/min | 10.5 | 10.9 | 16.5 | 17.2 |
| Outdoor unit | m3/min | 28.0 | 28.0 | 50.0 | 50.0 | |
| Acoustic power | Inner unit | dB(A) | 54 | 56 | 58 | 62 |
| Outdoor unit | dB(A) | 63 | 64 | 65 | 68 | |
| Acoustic pressure | High/silent inner unit | dB(A) | 37/19 | 38/19 | 41/25 | 45/26 |
| High exterior unit | dB(A) | 46 | 47 | 51 | 54 | |
| Operating range | Cooling | ℃ | -10-46 | -10-46 | -10-46 | -10-46 |
| Heating | ℃ | -15-24 | -15-24 | -15-24 | -15-24 | |
| Installation data | ||||||
| Voltage | Φ, V, Hz | 1st, 220-240V, 50 Hz | 1st, 220-240V, 50 Hz | 1st, 220-240V, 50 Hz | 1st, 220-240V, 50 Hz | |
| Type of compressor | Outdoor unit | Type | BLDC Rotary | BLDC Rotary | BLDC Rotary | BLDC Rotary |
| Energy consumption | Cooling | W | 700 | 1220 | 1390 | 1950 |
| Heating | W | 840 | 94 | 1710 | 2350 | |
| Running | Cooling | Has | 3.6 | 5.6 | 6.4 | 8.8 |
| Heating | Has | 4.0 | 4.5 | 7.8 | 10.5 | |
| Size | ||||||
| Net Dimensions (LxHxP) | Inner unit | Mr | 889x299x215 | 889x299x215 | 1055x299x215 | 1055x299x215 |
| Outdoor unit | Mr | 790x548x285 | 790x548x285 | 880x638x310 | 880x638x310 | |
| Net weight | Inner unit | Kg | 9.1 | 9.1 | 11.5 | 11.6 |
| Outdoor unit | 02/06/20 | 22.6 | 22.6 | 39.7 | 43.2 | |
| Refrigerant | ||||||
| Refrigerant | Type | R32 (these products contain R32. GWP-675) | ||||
| Pre-filling (for 5m) | Kg | 0.70 | 0.70 | 1.30 | 1.30 | |
| Co2 equivalent pre-fill | tCO2e | 0.47 | 0.47 | 0.88 | 0.88 | |
| Recharging of refrigerant | g/m | 15 | 15 | 15 | 15 | |
| Connecting the piping | Liquid piping | Mm (inch) | 6.35(1/4) | 6.35(1/4) | 6.35(1/4) | 6.35(1/4) |
| Gas pipeline | Mm (inch) | 9.52(3/8) | 9.52(3/8) | 12.70(1/2) | 12.70(1/2) | |
| Length of wiring | Min/Max (inside to outside) | Mr | 3/15 | 3/15 | 3/30 | 3/30 |
| Wiring height | Max | Mr | 8 | 8 | 15 | 15 |
| Connecting the piping | Evacuation line | Mm | 16.3, 550mm | 16.3, 550mm | 16.3, 550mm | 16.3, 550mm |
