Park of 110 kWh OPzV 48V batteries View full size

Park of 110 kWh OPzV 48V batteries

Hoppecke

25 816,56 € tax incl.

24 solar batteries Hoppecke OPzV 2300 Park

Junctions needed to connect to your battery Park are provided.



    logo hoppecke 10 weeks time

More details

More info

Hoppecke OPzV

> Park of 24 batteries Hoppecke {linkpopup id = 'opzv'} 2300

> 48 kWh battery capacity

> Batteries are delivered loaded and filled.

> Joints for the connection of your battery Park are provided.

{Linkpopup id = 'opzv'} batteries are based on technology of tubular plate for attachment of the electrolyte in the form of gel. These batteries are maintenance free with their sealed construction. Tubular plates offer a very high life expectancy for these batteries.

The range of products {linkpopup id = 'opzv'} is optimal for application in areas with high number of discharges as for example solar systems as well as for long landfill operations for example in computing / telecom or the security lighting applications.


Benefits



  • Optimal space - by setting horizontal and vertical use
  • No maintenance regarding the filling of water - by the innovative technology of the gel
  • Very good stability of cycle for use in PSoC1 - tubular plate design allows one effective charging current
  • Maximum compatibility - measures in accordance with the standard DIN 40742
  • Short-circuit security from the mounting - using System HOPPECKE connectors

Applications



  • On-grid and off-grid energy use
  • Drinking water treatment system
  • Medical treatment equipment
  • Signage, lighting
  • Mobile radio stations
  • BTS stations
  • Treatment of off-grid power systems / network

Cyclings



Life expectancy up to 1500 cycles at 80% depth of discharge.


Shelf life of cycles depending on the withdrawn capacity

cyclage hoppecke


Technical characteristics



Battery typeC100/1, 85V
Ah

C50/1, 85V
Ah

C24/1, 83V
Ah
C10/1, 80V
Ah
C5/1, 77V
Ah
Weight max KgLength L max mmWidth l MaxmmHeight H Max mmFig.
4 OPzV solar.power 250286,9263.5243,0204,1188,718.3105208420A
5 OPzV solar.power 310358,6329,3303,8255,1235,822.3126208420A
6 OPzV solar.power 370430,3395,2364,6306,1283,026.5147208420A
5 OPzV solar.power 420478.2452,9427,8391,4346,129.9126208535A
6 OPzV solar.power 520573,9543,4513,4469,7415,335.1147208535A
7 OPzV solar.power 620669,5634,0599,0548,0484,542.1168208535A
6 OPzV solar.power 750847,3802,2762,1682,0595,048.7147208710A
8 OPzV solar.power 10001129,81069,61016,2909,3793,365.9215193710B
10 OPzV solar.power 12501412,21337,01270,21136,7991,780.5215235710B
12 OPzV solar.power 15001694,71604,41524,21364,01190,094.6215277710B
10 OPzV solar.power 17001955,01870,01784,91544,61371,9110.0215277855B
16 OPzV solar.power 23002606,72493,32379,82059,51829,2152.9215400815C
20 solar.power OPzV 29003258,33116,72974,82574,32286,5186,5215490815D
24 OPzV solar.power 35003910,03740,03569,83089,22743,8222,3215580815D

C100, C50, C24, C10 and C5 = loading in 100, 50, 24, 10, and 5 hours

* According to the standard DIN 40742 these data are to be understood as maximum values


Specifications

Voltage24V
Battery capacity36 kWh
