GS SOLAR solar panel 50 Wp GS-50

€ 39,93
Belasting inbegrepen
GS-50
0712971125032

GS-50 solar panel, Amorphous laminated  (frameless), bi glass.

Excellent ratio power / quality / price

logo gs solar



50 artikel(en) in voorraad !

" Amorphous second generation model, occurs even in low light."



Characteristics :

  • Warranty: 5 year modules.
  • Normal operating temperature: 45 ° C
  • Wind Resistance: ? 130 km / h
  • Maximum diameter of the hailstone: 25 mm
  • Hailstone impact speed: 80 km / h
  • High transmission glass
  • Box "plug & play" with 3 LEDs



Guaranteed yield : 10 years at 90%

Guaranteed yield : 25 years at 80%

Specifications





Type Amorphous
Nominal Pm 50w
Tolerance on Pm +/-5%
Voc 62V
Voltage at max power 43V
Max current power 1,17A
Isc 1,42A
Max current system 1000V
Open circuit voltage 56,1V
Dimensions 1245 X 635 mm
Weight 14,4 Kg
Thikness  7,5 mm
Material glass
Frame No frame
Made in China





GS-50

Gegevensblad

Max. vermogen - Wp
50
Open-circuit spanning (Voc)
62 V
Kortsluitstroom (Isc)
1,42 A
Maximale voedingsspanning (Vmp)
43 V
Max. stroomsterkte (Imp)
1,17 A
Kleur
Classical
Type paneel
Rigids
Cellen
Amorphe
Breedte
635 mm
Hoogte
1245 mm
Frame
Without frame
Dikte
7,5 mm
Gewicht
14,4 kg

Specifieke referenties

upc
712971125032
ean13
0712971125032
