External Enwitech protection box for SolarEdge

€ 1.738,59
Belasting inbegrepen
10013682/Révision 1.0
0768563817625

The "NL/BE" external protection cabinet should be used exclusively in configuration with a SolarEdge "StorEdge" single-phase inverter with "SE5000-RWS" Backup function.
The external protective cabinet, the components used and the electrical wiring were tested and approved by the manufacturer SolarEdge.

Commentaar (0)

Geen klantenbeoordelingen op het moment.

"External protection box for SolarEdge "StorEdge"





• Application: "StorEdge" Backup System - SolarEdge
• PV/battery-compatible inverter: StorEdge SE5000-RWS
• Earth-linking scheme: TT or TN-S scheme; 1ph or 3ph (230/400V 50Hz) Connection: 1ph (230V/N)
• Separation of the network: All poles

Size

Size

Technical data



Characteristics
Rated tension AC [V] 1ph -230 (L/N)
Public network/building connection [V] 1AC or 3AC 230/400
Isolation nominal tension [V] 400
Frequency of operation [Hz] 50
Switchable short-circuit current max. [kA] 10
Authorized land link scheme (customer system) TT/TN-S
Earth-linking scheme in Backup mode TN-S
Phase coupling (Backup mode) (impossible)
Maximum consumer power allowed [kW] 4.5 (7 short-term - 300s)
Maximum crossing thermal power [kW] 12 (consumers - inverter)
Losses on standby [W] about 7
General data
Dimensions (LxHxP) [mm] 448x432x161
Weight [kg] 10
Operating temperature range [C] -20..40
Transport/storage temperature [C] -25..-55
Short-term maximum 24 hours [C] -25..-60
Condenser moisture X
Humidity - permissible range [%] 5 ... 95
Maximum installation altitude above sea level [m] 2000
IP Protection Index (EN 60529) 65
Outdoor installation X
Type of installation Inside
Protective class (EN 61140) Ⅱ
Case material Polycarbonate
RoHS Compliance (2011/65/EU) •
Case colour Similar to RAL7046
Type of assembly Wall mounting
Cover Transparent
Type of closure (actuation) Without tools
Standards/Standards
Set of equipment 61439-1
61439-2
61439-3
Stationary electrical energy storage systems VDE-AR-E 2510-2
Other
Tariff number 85371098
