Samsung Wind Free 2.6 and 3.5kW heat pump
Samsung Wind Free 2.6 and 3.5kW heat pump
Samsung Wind Free 2.6 and 3.5kW heat pump

Samsung Wind Free 2.6 and 3.5kW heat pump

1.642,62 €
Inklusive Steuer
AJ026TN1DKG/EU
0712971139596

AJ026TN1DKG/EU and AJ035TN1DKG/EU



  • Wind-Free™ technology, without draft
  • Energy saving.
  • Long air range
  • Low recess height
  • With lift pump

Kommentare (0)

Aktuell keine Kunden-Kommentare

Wind-Free 1-way Multi split cassette 3.5 kw

Wind-Free 1-way Multi split cassette 3.5 kw

Wind-Free refreshment™ is a new state-of-the-art technology for Samsung's new walls and cassettes. The Wind-Free 1-way cassette™ diffuses the air through the 10,000 micro-perforations of its façade, producing a subtle air flu, defiant or as "calm air". Micro-perforations and technology Wind-Free™ maintain a freshness without the usual unpleasant feeling of drafts


Comfort without draughtComfort without draught

Wind-Free technology™



The cooling by Wind-Free™ technology allows to maintain a freshness without the usual unpleasant feeling of air current: the fresh air is subtly diffused through the thousands of micro-perforations of the façade.




Better air diffusionBetter air diffusion

A broader strand



The wider and longer the flap, the faster the surface is cooled, evenly. The interior unit can broadcast fresh air up to 8 m (based on a 7.1 kW unit) with a wider operating angle, as well as a quick and regular refreshment.


Compact designCompact design


The height of the samsung 1-way cassette is only 135 m. the unit can be installed in a false low-rise ceiling and responds to many installation constraints.




Lighter interior unitLighter interior unit



Samsung is the first manufacturer to have designed its ABS chassis to make them the lightest units on the market.
Thus, thanks to compact dimensions and a reduced weight, the installation will be simpler and more flexible.




No overflow



Thanks to the lift pump's back valve, the water level of the recycling tray is kept to a minimum, the water does not stagnate and the risk of overflow is avoided.


Characteristics



Model Inner unit AJ026TN1DKG/EU AJ035TN1DKG/EU
Ability
  Cooling Kw 2.6 3.5
Chauffage@ 7c Kw 2.9 3.8
Performance
Airflow m3/h 372/312/252 456/396/336
Acoustic power Cooling dB(A) 50 55
Acoustic pressure H/M/B dB(A) 32/29/26 37/33/30
Installation data
Voltage Φ, #, V, Hz 1st, 220-240V, 50 Hz 1st, 220-240V, 50 Hz
Absorbed power Cooling W 45 50
Heating W 45 50
Nominal current Cooling Has 0.23 0.25
Heating Has 0.23 0.25
Size
Dimension (LxHxP) Mr 970X135X410 970X135X410
Weight Kg 10 10
Refrigerant
Piping connections Liquid Thumb 1/4 1/4
Gas Thumb 3/8 3/8
  Evacuation hose Mm VP20 (OD 26, ID 20) VP20 (OD 26, ID 20)
Other
Panel Model Code PC1NWFMAN PC1NWFMAN
Dimension (LxHxP) Mr 1198x35x500 1198x35x500
Weight Kg 4,3 4,3
Accessories Condensate pump Included Included
Max. Water Column/Transport mm/Litre/h 750/24 750/24
AJ026TN1DKG/EU

Datenblatt

Breite
970 mm
Höhe
135 mm
Dicke
410 mm
Gewicht
10 kg
