Ja Solar Solar Panel 395Wc Full Black JAM54S31 View full size

Ja Solar Solar Panel 395Wc Full Black JAM54S31

wattuneed.com

239,40 € tax incl.

Assembled with 11BB PERC cells, the half-cell configuration of the modules offers the advantages of higher power output, better temperature-dependent performance, reduced shading effect on power production, less risk of overheating, as well as better tolerance to mechanical loads.

More details

More info

Presentation JaSolar 395Wp solar panel

• Higher output power
• Less shading and less resistive losses
• Reduction of LCOE
• Mechanical load tolerance of the adjuster



Characteristics



TYPE
JAM54S31-395/MR
Rated maximum power(Pmax) [W]395
Open Circuit Voltage (Voc)36.98
Maximum Power Voltage (Vmp) [V]30.84
Short circuit current (Lsc) [A]13.7
Maximum power current (lmp) [A]12.73
Module Efficiency [%]20.2
Power tolerance0-+SW
Temperature coefficient of lsc(a_lsc)+o.o45%0c
Temperature coefficient of Voc(J3_ Voc)0.275%/°C
Temperature coefficient of Pmax(y_Pmp)0.350%/°C
TCC
lrradiance 1000W/m2, cell temperature 25°C, AM1 .5G
SPECIFICATIONS
CellMono
Weight21.5 kg±3
Size
1722±2mmx1134±2mmx30±1mm
Cable section size
4mm2 (IEC) , 12 AWG(UL)
Number of cells108(6x18)
Junction boxIP68, 3 diodes
Connector
MC4(1000V)
MC4-EVO2(1500V)

Specifications

CouleurFull Black
Panel typeRigids
CellsMonocrystalline
Max. Power - Wp390 Wc
