Eurener Total Black 300 Wc Solar Panel View full size

Eurener Total Black 300 Wc Solar Panel

Eurener energie solaire

150,26 € tax incl.

Eurener is one of the oldest module manufacturers in Europe: the Spanish company was founded in 1997. It is distinguished by above-average values.





More details

More info


Quality


IP68
6 diodes
High-transmission glass
Subjected to an electroluminescence test
Materials that respect the environment
Frame with greater mechanical resistance


Mechanical features



Framework

Silver anodise black 0.015 mm
Robust and corrosion-resistant
Incorporated land grab

Connection box

Waterproof, robust and wide to promote heat dissipation
IP67/IP68 compliant with IEC 60529
Incorporated by-pass diodes (3/6) to protect against partial shading areas
MC4 or compatible connector
Cables: 1m long and 4mm2 section
Reaction to Fire Class I (consistent with UNI 9177 standard)

Front

3.2 mm thick tempered glass and anti-reflections
Covered cell interconnections
Textured, low iron content, extra-clear

Solar cells

60 cells, monocrystalline silicon / 156x156 mm

Weight, size and packaging

19 Kg 1640 x 992 x 35mm Pack: 896 pcs-truck

20 Kg 1640 x 992 x 40mm Pack: 784 pcs-truck


Dimensions and curve



Data sheets and documentation

Specifications

Weight18,5 kg
CouleurFull Black
Panel typeRigids
CellsMonocrystalline
Max. Power - Wp300
Open circuit voltage (Voc)39,75 V
Short circuit current (Isc)9,89 A
Max. power current (Imp)9,37
Max. power voltage33,54 V
Pannel efficiency18,52 %
Width992 mm
Height1640 mm
Frame40 mm
