Kit 11 self-consumption panels / reinjection 3000W without storage
This kit includes
- 11XMULTIWAY Solar panel 435Wp HT54-18X
- 1XSingle-phase inverter SolaX X1 Boost 3.0T X1-3.0-T-D
- 2XSolar cable extension 2x4mm² with 4x MC4 connectors (20 meters)
- 1XEarth cable 1x6 mm2 20m
- 1XSchneider mono 16A circuit breaker
- 1XZJBENY DC double lightning arrester 2 inputs and 1 output 1000V 32A + 2m 10² cable
€249.35 (Tax incl.)
All our kits are configurable. In the options you can click on the product to choose another model or change the quantities to adapt the kit to your needs. You can also see the details of the chosen products directly below the price.
This kit is sized with the general purpose of being installed with the public network.
The basic composition of the kit contains 11 panels, a SolaX X1 Boost 3.0 Single Phase Inverter and the solar cable to connect the panels to the inverter. (The mounting system as well as the wiring and protections are modifiable to meet your needs).
SOLAR PANELS:
In its basic version, this Photovoltaic system will bring you an average of 12 Kwh per sunny day. The productions will depend on the seasons (summer/winter) the geographical position and the inclination of the panels.
We invite you to consult our solar production simulator to determine precisely what your solar production will be.
Warranty 25 years at 80% of rated power.
NETWORK INVERTER:
The SolaX X1 Mini range of inverters is designed and manufactured for small PV networks. With a starting voltage of 70V and a maximum efficiency of 97.1%, the X1 Mini promises unparalleled performance, allowing you to harvest as much energy as possible from your PV system.
CABLE AND CONNECTORS:
All cables and connections are pre-wired in our workshops. Our kits are very easily mountable by 'beginners' in electricity. For those who have some reservations about the technical side, our technical team assists you and helps you every day from 8am to 5pm.
ASSEMBLY:
The installation of this kit takes no more than 2 hours. Once the VarioTwin structures are positioned, all you have to do is 'clip' the panels on them. Attach the inverter to the wall and connect it to your electrical panel.
GUARANTEE:
All products have an individual warranty.
Panels guaranteed for 25 years at 80% of the rated power.
Solax inverter warranty 10 years.
Solar panel
The basic selected panel in this kit has been chosen according to our supplies.
You will find the characteristics of the latter by going to see its product sheet in the panel category.
Single-phase inverter SolaX X1 Boost 3.0T X1-3.0-T-D
SolaX has developed a range of single-phase inverters unmatched in the industry for their quality, reliability and efficiency. SolaX single-phase inverters have a wide MPPT voltage range that allows for greater energy recovery and a maximum input voltage of 600 V, with a maximum efficiency of 97.8%. In addition, SolaX single-phase inverters comply with the IP66 standard, have no internal fan and are equipped with an optional "plug & play" WIFI system. The "Boost" range with dual MPPT is also compatible with the new "Smart Plug" from SolaX that allows remote control of devices.
Characteristics
ENTRANCE | |
Max. power of photovoltaic panels (Wc) | 4500 |
Max. DC Power Recommended (W) | A: 3300 B: 3300 |
Max DC voltage (V) | 600 |
Nominal DC working voltage (V) | 360 |
Input current max. (A) | 12/12 |
Short circuit current max. (A) | 14/14 |
MPPT voltage range (V) | 70-580 |
Startup service voltage (V) | 100 |
# of MPP/MPPT follow-ups / Channels by MPP/MPPT follow-up | 2(1/1) |
AC OUTPUT | |
Rated AC Power (VA) | 3000 |
Max AC power (VA) | 3300 |
Rated electrical network voltage (AC voltage range) (V) | 220/230/240; 180~280 |
Frequency/Rated Range of the Power Grid (Hz) | 50/60; ±5 |
Rated AC current (A) | 13 |
Current AC max. (A) | 14,3 |
Displacement power factor | 0.8 capacitive – 0.8 inductive |
THDi, rated power(%) | <2 |
YIELD | |
MPPT Performance (%) | 99,9 |
European yield (%) | 97,0 |
Max yield (%) | 97,8 |
POWER ABSORBED | |
Standby (night) consumption (W) | <0.5 |
STANDARDS | |
Surge protection | Yes |
Overcurrent protection | Yes |
DC Insulation Resistance Monitoring | Yes |
Ground Fault Current Monitoring | Yes |
DC injection monitoring | Yes |
Differential circuit breaker protection | Yes |
Security | IEC 62109-1/-2 |
EMC | EN 61000-6-1, EN 61000-6-2, EN 61000-6-3 |
Certification | G98, G99, AS 4777, VDE4105, EN 50549, IEC 0-21 |
ENVIRONMENTAL LIMITS | |
Degree of protection (according to IEC 60529) | IP65 |
Operating temperature range (°C) | -25 to + 60 (downgrading to 45) |
Max operating altitude (m) | <2000 |
Humidity(%) | 0 to 100 (condensation) |
Storage temperature (°C) | -25~60 |
Typical sound level (dB) | 25 |
DIMENSIONS AND WEIGHT | |
Dimensions (W x W x D) (mm) | 430 x 341.5 x 143 |
Weight (kg) | 13,5 |
Type of cooling | Natural |
Topology | Non-isolated |
Communication interfaces | Pocket Wi-Fi (optional) Pocket LAN (optional) Pocket GPRS (optional) Counter (optional) SR485 DRM USB for update |
LCD | Yes |
Standard warranty (years) | 10 |
Connection scheme
Data sheet
- Inverter power
- 3000VA
- Kit output voltage
- 230V
- Type of need
- Self-consumption
- Battery storage
- Without storage
- Wind turbine
- Without
- Number of panels
- 11 panels
- Mains re-injection
- With
Specific References
- UPC
- 712971137950
- EAN13
- 0712971137950
