Self-consumption kit 9 panels 5kVA with storage
This kit includes
- 9XMULTIWAY Solar panel 435Wp HT54-18X
- 1XWKS Evo Circle 5.6 kVA 48V hybrid inverter
- 3X2X4mm2 solar cable with MC4 type (sold per metre)
- 1XEarth cable 1x6 mm2 20m
- 4XUltracell GEL battery 12V 200Ah
- 1XBattery cable 2x25mm2 - 2m
- 3X25mm² battery cable with pods
- 1XFuse box for battery - Coffret avec fusible pour batterie -100A
- 1XSchneider single-phase 25A circuit breaker
- 1XZJBENY DC double lightning arrester 2 inputs and 1 output 1000V 32A + 2m 10² cable
€249.35 (Tax incl.)
All our kits are configurable. In the options you can click on the product to choose another model or change the quantities to adapt the kit to your needs. You can also see the details of the chosen products directly below the price.
This kit is sized with the general purpose of supplying an isolated site or a stand-alone installation.
The basic composition of the kit contains 9 solar panels, a WKS Circle 5.6 kVA Single Phase Inverter, the solar cables to connect the panels to the inverter and from the inverter to your electrical panel, the panel mounting system is available as an option. (The mounting system as well as the wiring and protections can be modified to meet your needs).
SOLAR PANELS:
In its basic version, this photovoltaic system will bring you an average of 10.8kW per day. The productions will depend on the seasons (summer/winter) on the geographical position and the inclination of the panels.
We invite you to consult Our solar production simulator to determine precisely what your solar production will be.
Warranty 25 years at 80% of the rated power.
NETWORK:
WKS hybrid inverters are the ideal solution for Supplying a home with self-consumption or Make an isolated site autonomous. This inverter makes it possible to power consumers up to 5600W . The integrated MPPT 120A load controller allows up to 6000Wp of panels. Possibility to put him in input on public grid or generator for recharge the batteries. Fully configurable via the LCD screen of the inverter. In-house after-sales service, spare parts available
2 year warranty
BATTERIES:
What can I expect from my Lead Gel (gelled electrolyte) batteries?
GEL lead-acid batteries only need to be discharged to 50% of their capacity on a daily basis. For example, if your fleet has a capacity of 4.8kWh, care must be taken not to consume more than 2.4kWh.
In order to comply with the manufacturer's recommendations, the majority of GEL lead-acid batteries can only withstand faster discharges in 10 hours. If you have a fleet of 4 batteries of 100Ah in 48v, and therefore a total capacity of 4.8kWh, you should not consume more than 480W. The instantaneous photovoltaic production is to be added to this value. However, a slight margin is to be expected, indeed a lead-acid battery withstands faster discharges over a short period of time.
What can I expect from my lithium batteries?
Generally speaking, lithium batteries can be discharged much faster than stationary lead-acid batteries. They also allow more of their capacity to be used. It is common to be able to discharge them in an hour and be able to use up to 90% of their capacity.
How to know the capacity of your battery?
This is expressed in ampere hours, it is the product of the multiplication of the capacity (Ah) of the battery by the voltage (V) of it:
Example : 4 batteries of 100Ah of 12V mounted in series will give a voltage of 48V. These batteries will have a total capacity of 4.8kWh
48V * 100Ah = 4800 Wh = 4.8 kWh
How do I calculate my battery requirement?
In order to make your life easier, we have developed a tool to size your autonomous solar kit and the size of your battery park.
CABLE AND CONNECTORS:
All cables and connections are pre-wired in our workshops. Our kits are very easily assembleable by 'beginners' in electricity. For those who have some reservations about the technical side, our technical team assists you and helps you every day from 8am to 5pm.
ASSEMBLY:
The installation of this kit is very simple. Our instructions are clear and allow easy assembly without special knowledge. We answer all your questions before, during and after the installation of your system.
GUARANTEE:
All products have an individual warranty.
Panels guaranteed 25 years at 80% of the rated power.
WKS EVO Circle inverter with a 2-year warranty.
Solar panel
The basic selected panel in this kit has been chosen according to our supplies.
You will find the characteristics of the latter by going to see its product sheet in the panel category.
Hybrid inverter WKS Evo Circle 5.6 kVA 48V
The WKS EVO Circle is equipped with an MPPT solar charge controller that maximizes and regulates the DC power of the solar panel to charge your battery bank.
The transformerless design enables reliable power conversion in a compact form factor. The new generation of WKS has built-in Wi-Fi, mobile monitoring can be done through mobile apps. The data can be viewed and saved in the inverter, which is convenient for tracking the working status of the inverter. It also supports USB On-The Go feature for easy rewriting of internal settings, data downloads, and software updates.
Characteristics
Model | |
Rated power | 5600VA/5600W |
Entrance | |
AC input voltage | 170-280 VAC (for personal computers) |
Selectable voltage range | 90-280 VAC (for household appliances) |
Frequency range | 50Hz/60Hz (auto-detect) |
Exit | |
AC voltage regulation (Batt mode.) | 230 VAC +/- 5 |
Overload capacity | 5s@>/=150% charge;10s@110%~150% charge; 100ms @ >/=200% charge |
Yield (peak) | 93% |
Transfer time | 10 ms (for personal computers); 20 ms (for household appliances) |
Waveform | Pure sine wave |
AC output voltage | 24.3A |
Battery | |
Battery voltage | 48 VDC |
Floating charging voltage | 54 VDC |
Overload protection | 66 VDC |
Solar charger and AC charger | |
Type of solar charger | MPPT |
Maximum power of the PV generator | 6000W |
MPPT range at operating voltage | 120~430VDC |
Maximum voltage of the PV open circuit | 450VDC |
Maximum solar charging current | 120A |
Maximum AC charging current | 120A |
Physics | |
Dimension, D x W x H (mm) | 140x295x468 |
Net weight (kgs) | 11.0 12.0 |
Communication interface | USB/RS232/RS485/Wifi/Dry Contact |
Operating environment | |
Humidity | 5% to 95%a Relative humidity (non-condensing) |
Operating temperature | -10°C to 50°C |
Storage temperature | -15°C to 60°C |
Solar battery GEL Ultracell 12V 200Ah
Gel batteries are waterproof batteries: no maintenance, no addition of distilled water. Enhanced safety compared to open lead-acid batteries.
A gel battery can withstand 50% discharge and return to its rated capacity if the discharge time is short. This series has a longer discharge time compared to other batteries. Its special plate design increases battery life and especially in warmer temperatures. A separator within the battery improves its performance. It also has a longer shelf life.
- Rated voltage: 12V
- Capacity: 200Ah
- Dimensions: 522 x 240 x 218 mm
- Weight: 63 kg
Data sheet
- Solar kit type
- Kit 230V AC avec batterie
- Inverter power
- 5000VA
- Kit output voltage
- 230V
- Type of need
- Self-consumption
- Battery storage
- With storage
- Wind turbine
- Without
- Number of panels
- 9 panels
- Voltage
- 230V
- Battery
- Kit with battery
- Panel type
- Rigids
- Mains re-injection
- off-grid
Specific References
- UPC
- 712971136663
- EAN13
- 0712971136663
