Self-consumption kit 12 panels 5kVA OPZS

Wattuneed

7 306,97 € tax incl.

Add to cart

Self-consumption kit with 'ready-to-use' storage of 12 panels

This complete kit includes basic :

  • 9 panels TrinaSolar 265Wc
  • 1 inverter WKS 5kVA 48V
  • 4mm2 double insulation solar cable
  • 2 lithium Pylontech batteries 50

More details

Équipements
Descriptions équipements
Customize

Choix des panneaux

See product
Solar panel JNL Solar monocrystallin 320 Wc full black

config

173,37 €

QTT

See product
Solar panel Q.Cells DUO-G9 335Wc Full Black

config

217,80 €

QTT

See product
Solar panel Q.Cells DUO- ML-G9 390Wc monocrystallin

config

253,56 €

QTT

See product
TrinaSolar Vertex S 390Wc Full Black Solar Panel

config

239,47 €

QTT

See product
Solar panel Hyundai 400 Wc

config

257,70 €

QTT

See product
Monocrystalline solar panel TrinaSolar Vertex S 400Wc

config

245,60 €

QTT

See product
Solar panel Hyundai 400 Wc Ultra Black

config

260,05 €

QTT

Inverter selection

See product
UPS hybrid WKS Evo 48V 5kVA

config

949,85 €

QTT

See product
UPS hybrid WKS Evo 3kVA 24V

config

776,40 €

QTT

See product
3kW hybrid inverter injection network - Multisolar storage
Out of stock

config

1 593,17 €

QTT

See product
UPS hybrid 5kW injection network - storage Multisolar

config

2 460,33 €

QTT

See product
UPS hybrid 10kW injection network - storage Multisolar

config

4 208,78 €

QTT

See product
Sermatec 5kVa 48V hybrid inverter

config

1 790,00 €

QTT

See product
Sermatec 10kVa hybrid inverter

config

3 226,67 €

QTT

Choice of mounting system

49.1
Sélectionné

Slate roof attachment kit

55
Sélectionné

Tile roof attachment kit

127
Sélectionné

Fixing kit on ground structure

37.28
Sélectionné

Tin roof attachment kit

85.92
Sélectionné

Système de montage pour toitures plates FlatFix

42.84
Sélectionné

Mounting system for tray roofing

See product
Slate roof attachment kit

config

49,10 €

QTT

See product
Tile roof attachment kit

config

55,00 €

QTT

See product
Fixing kit on ground structure

config

127,00 €

QTT

See product
Tin roof attachment kit

config

37,28 €

QTT

See product
Système de montage pour toitures plates FlatFix

config

85,92 €

QTT

See product
Mounting system for tray roofing

config

42,84 €

QTT

Wiring and connections

See product
2X4mm2 solar cable with Type MC4 (sold by the meter - 15m)

config

35,81 €

QTT

See product
2X4mm2 solar cable with MC4 type (sold per metre)

config

4,60 €

QTT

See product
2x4mm² Solar cable extension with 2xMC4-like (by the meter)

config

7,30 €

QTT

See product
Earth cable 6mm2 1m

config

1,45 €

QTT

See product
Male and female MC4-like connectors

config

5,00 €

QTT

See product
Double type MC4-like connector male & female

config

16,00 €

QTT

AC protection and accessories

See product
Schneider mono 20A circuit breaker

config

8,60 €

QTT

See product
Schneider single-phase 25A circuit breaker

config

16,00 €

QTT

See product
3kWc Single Phase lightning protection

config

232,42 €

QTT

See product
Three-phase electrical box

config

673,92 €

QTT

See product
AC Parafoudre Box

config

359,37 €

QTT

See product
AC ZJBENY box set with 25A 230V socket

config

140,00 €

QTT

See product
ZJBENY AC 25A 230V Lightning Box

config

125,25 €

QTT

DC protection and accessories

See product
ZJBENY DC single-surge arrestor box

config

143,00 €

QTT

See product
1000V 32A DC double surge protector ZJBENY

config

231,00 €

QTT

See product
Paralleling Box 5 inputs with lightning arrester and switch

config

270,00 €

QTT

See product
DC 500V 32A disconnector box

config

129,00 €

QTT

See product
DC 2P 1000V 32A Switch - with enclosure

config

56,00 €

QTT

See product
Double DC Cut-out and lightnin protection box

config

551,98 €

QTT

See product
DC Cut-out and lightning protection box 20A

config

262,85 €

QTT

See product
DC Cut-out and protection box 40A

config

457,03 €

QTT

Battery Accessories

See product
16mm² battery cable with pods

config

5,80 €

QTT

See product
25mm² battery cable with pods

config

9,00 €

QTT

See product
50mm² battery cable with pods

config

12,00 €

QTT

See product
Battery cable 2x4mm2 - 2m

config

9,90 €

QTT

See product
Battery cable 2x16mm2 - 2m

config

17,90 €

QTT

See product
Battery cable 2x25mm2 - 2m

config

30,30 €

QTT

See product
Battery cable 2x50mm2 - 2m

config

70,60 €

QTT

See product
Hoppecke AquaGen premium top V

config

42,40 €

QTT

Choix des batteries

See product
Hoppecke OPzS solar.power battery

config

171,50 €

QTT

See product
Hoppecke OPzV solar.power battery

config

210,10 €

QTT

More info

All our kits are configurable. In the options you can click on the product to choose another model or change the quantities to suit the kit to your needs. You can also see the details of the selected products directly below the price.

This kit is sized with the general purpose of powering an isolated site or a stand-alone installation.

The basic composition of the kit contains 12 320Wc JNL Solar panels (modifiable for panels according to your choice), a 5 kVA WKS Monophasé Inverter, solar cables to connect the panels to the inverter and the inverter to your electrical panel, the panel mounting system is available as an option. (The assembly system as well as the wiring and protections are changeable to meet your needs).



SOLAR PANELS:

In its basic version, this Photovoltaic system will bring you an average of 10.8kW per day. Productions will depend on the seasons (summer/winter) on the geographical position and the inclination of the panels.
We invite you to consult our solar production simulator to determine exactly what your solar production will be.

20-year warranty at 80% of rated power.



INVERTER:

WKS hybrid inverters are the ideal solution for fueling a home with self-consumption Yes make an isolated site self-sufficient. This inverter can be used to power consumers up to 5000W. The built-in MPPT 80A charging controller allows you to take up to 4000Wc of panels. It is possible to put him in the public network or generator for recharge the batteries. Totally set up via the LCD screen of the inverter. SAV provided in-house, spare parts available

2-year warranty



CABLE AND CONNECTORS:

All cables and connection are pre-wired in our workshops. Our kits are very easily mounted by 'beginners' in electricity. For those who have some reservations about the technical side, our technical team assists you and helps you every day from 8am to 5pm.



assembly:

The installation of this kit is very simple. Our instructions are clear and allow easy editing without any special knowledge. We answer all your questions before, during and after installing your system.



guarantee:

All products have an individual warranty.
Panels guaranteed 20 years at 80% of rated power.
WKS inverter guaranteed 2 years.


Panneau solaire JNL SOLAR 300Wc Monocristallin Full Black



Solar Panel JNL Solar monocrystalline 320 Wc full black

JNL Solar is dedicated to the development, operation, maintenance of solar power plants, the manufacture of R&D rings and the manufacture of solar modules, solar cells.
It has equipped a state-of-the-art professional automatic production line and has state-of-the-art technique and craftsmanship.









Characteristics



Peak power (Pmax)320
Module efficiency19,18%
Voltage power Vmp (V)33.5
Current power imp (a)9.55
Open circuit voltage Voc (V)39.9
Short circuit current Isc (A)10.08
Power tolerance- 0, +5W
Maximum System Voltage (V) Max Series Fuse Rating
DC 1000V / 1500V - 15A
Dimensions
1665 x 1002 x 35
Weight (kg)19.0
Type of solar cells
Monocrystalline 158.75mm x 158.75mm
Junction boxIP67
Mechanical loading5400Pa
Frame
Anodized aluminum alloy


WKS EVO 5 kva 48V hybrid inverter



WKS EVO 5KVA 48V hybrid inverter



WKS hybrid inverters are the ideal solution for fueling a home with self-consumption Yes make an isolated site self-sufficient
This inverter can be used to power consumers up to 5000W
The built-in MPPT 80A charging controller allows you to take up to 4000Wc of panels
It is possible to put him in the public network or generator for recharge the batteries
Totally set up via the inverter's LCD screen
SAV provided in-house, spare parts available.

Built-in Bluetooth app, Android app (WatchPower) available and removable LCD control module with multiple communications





Characteristics



power5000VA / 5000W
ENTREE AC
tension230 VAC
Tension range110-280 VAC
frequency50 Hz/60 Hz (automatic detection)
EXIT AC
Ac voltage regulation (Batt. Fashion)230VAC ± 5%
Peak power (5 sec)

10,000VA

yield93%
Transfer time0 ms
exitPure Sinus
BATTERY AND CHARGER AC
Rated battery voltage48 VDC
Types of batteriesAGM, GEL, open (parametrable)
Load algorithm3 steps
Floating tension54 VDC
Overload protection66 VDC
Maximum charge current60A (adjustable)
SOLAR CHARGER
Max PV power4000 W
MPPT operating range60 - 115 VDC
Maximum PV voltage in open circuit145 VDC
Max charge current80 A
Max return98%
Consumption in standby2 W
physics
Dimension, D x W x H (mm)140 x 303 x 525
Weight (kgs)13.5
environment
humidity5% to 95%
Operating temperature0C - 55C
Storage temperature-15C - 60C


Hoppecke OPzS Solar.Power Battery



Hoppecke OPzS Solar.Power Battery



Hoppecke opzs are single cell batteries ventilated with liquid electrolyte (diluted sulphuric acid). They are ideal for applications that require a lot of charge-discharge cycles (solar applications).

The tubular design of the plates allows for a more efficient charge current and good stability during use. These Hoppecke batteries have a long lifespan and are suitable for use in cycling.

Aquagen for gas recombination is not supplied with batteries.






Connection order

(1) Batteries with the inverter;
(2) Panels in the inverter.









Specifications

Wind TurbinWithout
Number of panels9 panels
Output Kit voltage230V
Battery storageWith storage
Type de kit solaireKit 230V AC avec batterie
Type of needSelf-consumption
Voltage230V
Panel typeRigids
BatteryKit with battery
Inverter power5000VA
Grid reinjectionoff-grid
