Kit 6 panels consumption / reinjection 5000W with lithium storage

Wattuneed

12 634,30 € tax incl.

Add to cart

Kit with 'ready to use' storage consumption of 6 panels

This complete kit includes basic :

  • 6 panels TrinaSolar 265Wc
  • 1 MultiSolar 48V 3kVA inverter
  • Solar double insulated 4 mm² cable
  • 4 batteries GEL Ultracell 12V 100Ah

Optional:

  • Mounting system.
  • Electric protection
  • Auxiliary power system (wind turbine / generator)

Kit all in one and ready to use for your installation and an ideal consumption for a small household.

More details

Équipements
Descriptions équipements
Customize

Choice of panels

See product
Solar Panel JNL solar polycrystalline 280 WC

config

111,13 €

QTT

See product
TrinaSolar poly 290Wc solar panel

config

120,46 €

QTT

See product
Solar panel Hanover solar 320Wc Monocristallin Black

config

135,81 €

QTT

See product
JA SOLAR 320Wc Mono Solar Panel

config

167,60 €

QTT

See product
Solar panel Q.Cells DUO-G6 335Wc mono Full Black

config

202,00 €

QTT

See product
LG 340Wc NeON 2 monocrystallin Full Black solar panel

config

343,86 €

QTT

See product
Hyundai 345 Wc Full Black Solar Panel

config

205,00 €

QTT

See product
LG 365Wc NeON R monocrystalline solar panel

config

441,65 €

QTT

See product
Solar panel Q.Cells DUO 360Wc G8 mono

config

200,00 €

QTT

INVERTER SELECTION

See product
Sermatec 10kW hybrid inverter

config

3 226,67 €

QTT

See product
Sermatec 5kW 48V hybrid inverter

config

1 790,00 €

QTT

See product
UPS hybrid 5kW injection network - storage Multisolar

config

2 460,33 €

QTT

See product
UPS hybrid 10kW injection network - storage Multisolar

config

4 208,78 €

QTT

CHOICE OF THE MOUNTING SYSTEM

49.1
Sélectionné

Mounting system for slates roof

55
Sélectionné

Mounting system for tile roof

127
Sélectionné

Free-land mounting kit for solar panel

37.28
Sélectionné

Mounting system for sheet metal

82.62
Sélectionné

Système de montage pour toitures plates FlatFix

See product
Mounting system for slates roof

config

49,10 €

QTT

See product
Mounting system for tile roof

config

55,00 €

QTT

See product
Free-land mounting kit for solar panel

config

127,00 €

QTT

See product
Mounting system for sheet metal

config

37,28 €

QTT

See product
Système de montage pour toitures plates FlatFix

config

82,62 €

QTT

CABLING AND CONNECTORS

See product
2X4mm² Solar cable with MC4 (by the metre)

config

4,60 €

QTT

See product
2X4mm² Solar cable with MC4 (5metre)

config

13,80 €

QTT

See product
2X4mm² Solar cable with MC4 (10 metre)

config

24,79 €

QTT

See product
2X4mm² Solar cable with MC4 (20 metre)

config

46,80 €

QTT

See product
2X4mm² Solar cable with MC4 (15 metre)

config

35,81 €

QTT

See product
2x4mm² Solar cable extension with 2xMC4 (by the meter)

config

7,30 €

QTT

See product
Male and female MC4 connectors

config

5,00 €

QTT

See product
Double MC4 connector male & female

config

16,00 €

QTT

See product
Triple MC4 connector male + female

config

24,00 €

QTT

See product
Earth cable 6mm2 1m

config

1,45 €

QTT

AC guards and accessories

See product
Schneider Breaker tetra 16A

config

39,69 €

QTT

See product
Schneider Breaker mono 2A

config

13,13 €

QTT

See product
Schneider Breaker mono 4A

config

13,13 €

QTT

See product
Schneider Breaker mono 6A

config

13,31 €

QTT

See product
Schneider Breaker mono 10A

config

16,50 €

QTT

See product
Schneider Breaker mono 16A

config

8,13 €

QTT

See product
Schneider Breaker mono 20A

config

8,13 €

QTT

See product
Schneider Breaker mono 25A

config

14,48 €

QTT

See product
Schneider Breaker mono 40A

config

15,10 €

QTT

See product
Schneider Breaker tetra 20A

config

39,69 €

QTT

See product
Schneider Breaker tetra 25A

config

39,69 €

QTT

See product
Schneider Breaker tetra 40A

config

45,74 €

QTT

See product
Schneider Breaker tetra 50A

config

183,68 €

QTT

See product
Differential switch type A 4P 40A 300ma

config

82,00 €

QTT

See product
Differential switch type A 2P 63A 300ma

config

69,50 €

QTT

See product
Differential switch type A 2P 63A 300ma

config

119,80 €

QTT

DC guards and accessories

See product
Paralleling Box 5 inputs with lightning arrester and switch

config

270,00 €

QTT

See product
ZJBENY DC single-surge arrestor box

config

143,00 €

QTT

See product
ZJBENY double DC surge-arrestor box

config

231,00 €

QTT

See product
DC 500V 32A Switch box

config

129,00 €

QTT

See product
DC 500V 40A Switch

config

68,00 €

QTT

See product
DC 2P 1000V 32A Switch - with enclosure

config

56,00 €

QTT

Choice of batteries

See product
Pylontech Lithium Battery H48050 -200

config

4 914,46 €

QTT

See product
Pylontech Lithium Battery H48050 -250

config

6 143,07 €

QTT

See product
Pylontech Lithium Battery H48050 +300

config

7 371,70 €

QTT

See product
Pylontech Lithium Battery H48050 +350

config

8 600,30 €

QTT

See product
Pylontech Lithium Battery H48050 +400

config

9 828,93 €

QTT

See product
Pylontech Lithium Battery H48050 +450

config

11 057,54 €

QTT

Choice of WSB

See product
Pylontech control module SC-0500-100S

config

986,61 €

QTT

See product
BMS Pylontech SC1000-100S

config

1 182,07 €

QTT

Battery Accessories

See product
16mm² battery cable with pods

config

5,80 €

QTT

See product
25mm² battery cable with pods

config

9,00 €

QTT

See product
50mm² battery cable with pods

config

12,00 €

QTT

See product
Storage cabinet for 4 batteries

config

129,10 €

QTT

See product
Storage cabinet for 8 batteries

config

182,30 €

QTT

See product
Rack server 19 "12U wall cabinet

config

326,60 €

QTT

See product
Rack 19 "for pylontech with shelf Cabinet

config

1 150,00 €

QTT

See product
Storage cabinet for 20 batteries

config

359,00 €

QTT

More info

All our kits are configurable. In the options you can click on the product to choose another model or change the quantities to adapt the kit to your needs. You can also see the details of the selected products directly below the price.

This kit is designed with for general purpose feeding a remote site or a stand-alone installation.

The composition of base kit contains 6 panels solar JNL Solar 300 Wc, a inverter Sermatec 5kW, the cables to connect the panels to the ups and the ups to your electric Panel, the system of mounting the panels solar is available in option. (The Assembly and wiring and protection system can be changed to match your needs).



SOLAR PANELS:

In its basic version, this photovoltaic system will bring you an average 30 Kwh on sunny day. The productions will depend on seasons (summer and winter) geographical position and tilt of the panels.

We invite you to visit our Solar Simulator in order to determine precisely what will be your solar production.

20 year warranty on 80% of the nominal power.



CABLE AND CONNECTORS:

All the cables and connections are pre-wired in our workshops. Our kits are very easily mountable by 'beginner' electricity. For those who would have some reservations about the side technical, our technical team assists you and helps you daily from 8: 00 to 17: 00.



EDITING:

The installation of this kit is simple. Our instructions are clear and allow easy mounting without special knowledge. We answer your questions before, during and after the installation of your system.



WARRANTY:

All products have an individual guarantee.
Panels guaranteed 20 years 80% of the nominal power.
Inverter Sermatec 2 years warranty.




Solar Panel JNL solar 300 WC monocrystalline full black



JNL solar is dedicated to the development, operation, maintenance of solar power plants, the manufacture of R&D rings and the manufacture of solar modules, solar cells.
It has equipped an advanced professional automatic production line and has an advanced technique and craftsmanship.
JNL solar has participated in national and international investment plans in the field of energy, such as the United States, Germany, France, Spain, Japan, India, South Africa, South Korea, Canada, etc. and all the power plants are successful on the network and the production wells.





Characteristics



Peak power (Pmax)300
Module efficiency18.33%
Max. supply voltage VMP (V)33.54
Max. power current amplifier (A)8.95
Vacuum voltage VOC (V)39.53
Short-circuit current ISC (A)9.6
Power tolerance-0, + 10W
Maximum system voltage (V)DC 1000V
Number of bypass diodes3
Blown fuse current15A
STC: irradiance 1000 W/m², cell temperature 25 °c, air mass AM 1.5 measurement tolerance: +-3%
Potentially induced degradation (PID) free, IEC61215, IEC61730, increased snow load up to 5400Pa.
Dimensions [mm]1650x992x35
Weight (kg)18.5
Type of solar cells156, 75mm x 156, 75mm (5BB)
Junction boxIP67
Mechanical loading5400Pa
FrameworkBlack anodized aluminium
Cables4mm2, 1000mm
ConnectorMC4 or compatible
glass3, 2mm
Operating temperature-40 °C-85 °C
Nominal temperature of the measuring cell47 in. +/-2 °c



Sermatec 5kW 48V Hybrid Indutor



It allows users to produce their own energy, to get certain economic benefits.
When there is enough solar energy, the inunntor draws energy from the PV station to power consumers, and the remaining power will charge energy from the batteries. The inundor automatically powers the battery charge.

• Rated capacity: 5KW;
• Maximum PV input capacity: 6000W, supports 2 MPPT trackers;
• Supports paralleling to increase production capacity (Under development).



Features





ModelSMT-5K-TL-UN
PV PV (DC)
Recommended DC diet6000
DC rated power (W)5000
Max. Tension Continues (V)580 V
MPPT voltage range (V)125-550 V
Start voltage (V)125
Maximum entry current (A)11th A
Maximum current protection (A)15
Number of MPPT trackers2
DC (Drums) output
Battery typeLi-Ion or Lead-acid
Rated battery voltage (V)48
Battery voltage range (V)40-58
Battery capacity (Ah)Programmable as needed
Load curve3 steps
Max. Charge Tension (V)60
Max. Charge current (A)70
Over-intensity protection (A)100
Maximum load power (W)4600 adjustable
Maximum load efficiency (%)95
Maximum discharge current (A)100
Maximum discharge power (W)4600
Maximum discharge yield (%)96
Entry (AC)
Network voltage range (V)170V-280V AC
Network frequency (Hz)50Hz/60Hz
Network Input Power (W)6000
Maximum entry current (A)15
Exit (AC)
Grid typePhase
Nominal network power (W)5000
Peak power (off-grid)110% charge: 30 minutes charge 120%: 5 minutes 150% charge: 5S
Nominal output50/60Hz; 230vac
Exit beach45-55Hz/55-65Hz; 180-270Vac
Maxi output current (A)22.8
Over-intensity protection (A)32
Total harmonic distortion (THD, rated power) (%)3
Displacement power factor-0.9 - 0.9
Backup output (with battery)
Grid typeMonphase
Rated backup power (W)4600
Nominal output50/60Hz; 230vac
Exit beach45-55Hz/55-65Hz; 180-270Vac
Maxi output current (A)15
Over-intensity protection (A)25 kg
Peak output power (W)4800W 5Mins 6000W 5S
Total harmonic distortion (THD, rated power) (%)3
Displacement power factor-0.9 - 0.9
Instant recovery time20ms
Peak factor03:01:00
UPS Switching Time (MS)10ms
Efficiency
MPPT Efficiency (%)99,9
Efficiency of Europe (%)97
Maximum return.97,6
Battery charge/discharge efficiency (%)'95
Protection
Anti-island protectionIntegrated
CC Switch (PV)Integrated (optical)
Protection against output current over-intensitiesIntegrated
Protection against short-circuit exitIntegrated
Exit surge protectionIntegrated

 Battery lithium Pylontech + 50



Latest model of battery HESS of Pylontech +.

This Lithium battery model already supplies more than 5,000 homes. An exceptional life, quality energy. The design facilitates the installation and expansion of your system. This battery reflects all the real requirements of end users and the highest technical capabilities of Pylontech.

You can find the 5 year warranty in attached files. Save it on the site of Pylontech allows you to extend the duration of the warranty for 7 years.



Features



         PARAMETERSPYLONTECH + 50
NominalRated voltage (V)48
PhysicsRated capacity (Ah)50
ElectricDimensions (mm)440 * 410 * 89
OtherWeight (Kg)24
 Discharge voltage (V)45 ~ 54
 Charge voltage (V)52.5 ~ 54
 Maximum discharge power (kW)5kW@1Min
 Maximum load power (kW)5kW@1Min
 CommunicationRS232, RS485, CAN
 Temperature0℃ ~ 50℃
-10℃ ~ 50℃
 Temperature of the shelf-20℃ ~ 60℃
 CertificationTÜV / THIS / UN38.3 / TLC
 Life10 + Years (25℃/77℉)
 Number of charging cycles> 4500 (25℃, 90% DoD)

Connection order



1• Batteries to the inverter;
2• Panels to the inverter.



Specifications

Wind TurbinWithout
Number of panels25 panels
Output Kit voltage230V
Type of needSelf-consumption
Battery storageWith storage
Type de kit solaireKit 230V AC avec batterie
Type of needOff-grid
Type of needUninterruptible power supply
BatteryKit with battery
Inverter power10000 VA
Grid reinjectionoff-grid
Grid reinjectionWith
