    Self-consumption Kit 6 solar panels and wind turbine
    Self-consumption Kit 6 solar panels and wind turbine
    Self-consumption Kit 6 solar panels and wind turbine
    Self-consumption Kit 6 solar panels and wind turbine
    Self-consumption Kit 6 solar panels and wind turbine
    Self-consumption Kit 6 solar panels and wind turbine
    Self-consumption Kit 6 solar panels and wind turbine
    Self-consumption Kit 6 solar panels and wind turbine
    Self-consumption Kit 6 solar panels and wind turbine
    Self-consumption Kit 6 solar panels and wind turbine
    Self-consumption Kit 6 solar panels and wind turbine
    Self-consumption Kit 6 solar panels and wind turbine
    Self-consumption Kit 6 solar panels and wind turbine
    Self-consumption Kit 6 solar panels and wind turbine
    Self-consumption Kit 6 solar panels and wind turbine

    Self-consumption Kit 6 solar panels and wind turbine

    €6,054.29
    Tax included
    config-ac-6pan-éol
    0712971134768
    100% secure payments

    This kit includes

    • 6XHT-SAAE MULTIWAY+ Solar panel 435Wp HT54-18X
    • 1XWKS Evo Circle 5.6 kVA 48V hybrid inverter
    • 1X2X4mm2 solar cable with MC4 type (sold per metre)
    • 1X1X4mm2 solar cable (sold per metre)
    • 1XEarth cable 1x6 mm2 20m
    • 1XSchneider single-phase 25A circuit breaker
    • 1XZJBENY DC double lightning arrester 2 inputs and 1 output 1000V 32A + 2m 10² cable
    • 1XLithium battery Pylontech US5000 +100 - 4.8kWh
    • 1XPylontech battery connection cable
    • 1XWind turbine Newmeil x-2000

    Select products from the sections below
    Panneaux
    info
    HT-SAAE MULTIWAY+ Solar panel 435Wp HT54-18X
    Price per unit
    €106.60  (Tax incl.)
    Choix de l'onduleur
    info
    WKS Evo Circle 5kVA 48V hybrid inverter
    WKS Evo Circle 5.6 kVA 48V hybrid inverter
    Price per unit
    €1,042.46  (Tax incl.)
    Choix du système de montage
    info
    No products selected
    Price per unit
    €0.00  (Tax incl.)
    Câblage et connectique
    info
    2X4mm² Solar cable with MC4 (by the metre)
    2X4mm2 solar cable with MC4 type (sold per metre)
    Price per unit
    €38.03  (Tax incl.)
    Câblage et connectique
    info
    1X4mm2 solar cable (sold per metre)
    1X4mm2 solar cable (sold per metre)
    Price per unit
    €58.07  (Tax incl.)
    Câblage et connectique
    info
    Earth cable 1x6 mm2 10m
    Earth cable 1x6 mm2 20m
    Price per unit
    €49.20  (Tax incl.)
    Protections et accessoires AC
    info
    Schneider Breaker mono 25A
    Schneider single-phase 25A circuit breaker
    Price per unit
    €18.00  (Tax incl.)
    Protections et accessoires DC
    info
    Choix des batteries
    info
    Lithium battery Pylontech US5000 +100 - 4.8kWh
    Lithium battery Pylontech US5000 +100 - 4.8kWh
    Price per unit
    €1,586.80  (Tax incl.)
    Accessoires batteries
    info
    Pylontech battery connection cable
    Pylontech battery connection cable
    Price per unit
    €25.65  (Tax incl.)
    Choix de l'éolienne
    info
    Wind turbine Newmeil x-2000
    Price per unit
    €2,347.16  (Tax incl.)

    Self-consumption Kit 6...

    €6,054.29

    All our kits are configurable. In the options you can click on the product to choose another model or change the quantities to adapt the kit to your needs. You can also see the details of the chosen products.

    This kit is sized to be setup off-grid.

    The basic composition of the kit contains 6 solar panels, a Single-phase Inverter WKS Circle 5.6 kVA, cables solar energy to connect(bind) panels(signs) with the inverter and of the inverter in your electrical panel, the system of assembly of panels is available optional. (The system of assembly as well as the cabling and the protections are modifiable to correspond to your needs).



    SOLAR PANELS :

    In its basic version, this Photovoltaic system will bring you on average 7.2 kW a day. The productions will depend on seasons (summer/winter) of the geographical position and the slope of panels. We invite you to consult our simulator of solar production to determine exactly what will be your solar production.

    Warranty of 25 years in 80 % of the rated output.



    INVERTER :

    WKS hybrid inverters 5kVA are the ideal solution for supplying a home with self-consumption or making an isolated site autonomous. This inverter provides power to consumers up to 5600W. The built-in MPPT 120A load controller allows up to 6000Wc of panels. Possibility to connect it in the input to the public grid or a generator to recharge the batteries. Fully configurable via the LCD screen of the inverter. After Sales Service insured internlly, spare parts available.

    Warranty of 2 years



    BATTERIES:

    What can I expect from lead batteries ?
    GEL lead batteries should only be discharged at 50% of their capacity on a daily basis. If your fleet has a capacity of (eg) 4.8kWh, you should be careful not to consume more than (eg) 2.4kWh on it.
    In order to comply with the manufacturer's recommendations, the majority of GEL lead-acid batteries can withstand faster discharges than in 10 hours. On a park of 4 batteries of 100Ah in 48v having 4.8kWh of capacity, you should only consume 480W per hour maximum to which it is necessary to add the instant production of the panels. A slight margin is expected, however, a lead battery supports faster discharges for a short time.

    What can I expect from my Lithium batteries?
    In general, lithium batteries can be discharged much faster than stationary lead batteries. They also make it possible to use a greater part of their capacity. It is common to be able to discharge them in one hour and to be able to use up to 90% of their capacity.

    How to know the capacity of your battery?
    This one is expressed in amperes hours, it is the product of the multiplication of the capacity (Ah) of the battery by the tension (V) of this one: Example: 4 batteries, 100Ah of 12V mounted in series will give a voltage of 48V, will have a total capacity of 4.8kWh
    48V * 100Ah = 4800 Watts / hour = 4.8 kW / h

    How to calculate my battery requirement?
    To make your life easier, we have developed a tool to size your self-contained solar kit and the size of your battery park.

    Click here !



    WIND TURBINE :


    Domestic Wind Turbine Newmeil X-2000. Suitable for nautic use or urban and isolated sites. With its aerodynamic profile and durability, the wind turbine Newmeil x-2000 is ideal for marine use . Its silence and veryquiet vibrations, makes it particularly suitable for city use.



    CABLE AND CONNECTORS :


    All the cables and the connecting are pre-cabled in our studios(workshops). Our kits are very easily mountable by 'beginner' in electricity. For those who would have some reluctances as for the technical side, our technical team assists you and helps you every day from 8 am till 5 pm.



    MOUNTING SYSTEM :

    The installation of this kit is very simple. Our notes are clear and allow an easy assembly(editing) without particular knowledge. We answer all your questions before, hanging and after the installation of your system.



    WARRANTIES :

    All these products have an individual guarantee.

    Panels(Signs) warranty of 25 years in 80 % of the rated output.

    Inverter WKS EVO CIRCLE warranty of 2 years.




    Panneau solaire Cortex Omnis 405





    Solar panel



    The basic selected panel in this kit has been chosen according to our supplies.
    You will find the characteristics of the latter by going to see its product sheet in the panel category.














    Onduleur hybride WKS Evo Circle 5,6 kVA 48V





    Hybrid inverter WKS Evo Circle 5.6 kVA 48V



    The WKS EVO Circle is equipped with an MPPT solar charge controller that maximizes and regulates the DC power of the solar panel to charge your battery park.
    Transformerless design enables reliable power conversion in a compact form factor. The new generation of WKS has a built-in Wi-Fi function, mobile monitoring can be done through mobile apps. The data can be viewed and saved in the inverter, which is convenient for tracking the operating status of the inverter. It also supports USB On-The Go feature for easy rewriting of internal settings, data downloads, and software updates.











    Characteristics



    Model
    Rated power5600VA/5600W
    Entrance
    AC input voltage
    170-280 VAC (for personal computers)
    Selectable voltage range
    90-280 VAC (for household appliances)
    Frequency range
    55Hz/60Hz (automatic detection)
    Exit
    AC voltage regulation (Batt. mode)230 VAC +/- 5
    Overload capacity
    5s@>/=150% charge;10s@110%~150% charge; 100ms @ >/=200% charge
    Yield (peak)93%
    Transfer time
    10 ms (for personal computers); 20 ms (for household appliances)
    Waveform
    Pure sine wave
    Battery
    Battery voltage48 VDC
    Floating charging voltage54 VDC
    Overload protection66 VDC
    Solar charger and AC charger
    Type of solar chargerMPPT
    Maximum power of the PV generator6000W
    MPPT range at operating voltage120~430VDC
    Maximum voltage of the open circuit of the PV450VDC
    Maximum solar charging current120A
    Maximum AC charging current120A
    Physics
    Dimension, D x W x H (mm)140x295x468
    Net weight (kgs)11.0 12.0
    Communication interface
    USB/RS232/RS485/Wifi/Dry Contact
    Usage environment
    Humidity
    5% to 95%a Relative humidity (non-condensing)
    Operating temperature
    From -10°C to 50°C
    Storage temperature
    From -15°C to 60°C




    Wind turbine Newmeil x-2000





    Wind turbine Newmeil x-2000



    • SUPPLIED WITH ITS CHARGING REGULATOR
    • SILENT AND VIBRATION-FREE
    • LIGHTWEIGHT AND COMPACT
    • PERFECT FOR SMALL APPLIANCES











    Wind turbine
    Model2000
    Type of wind turbineHorizontal axis, upstream of the wind
    Rotor diameter1900 mm
    Net weight24.5 kg
    Tower Diameter48-60 mm
    Number of blades5
    Blade materialsCarbon-fibre-reinforced plastic
    Blade mass660g/pcs
    Body materialAluminium sunk under pressure
    Construction of the bodyworkInside screw connection
    Product finishThermo powder coating-based clamp
    Connection of the towerbridle fitting or bolt bridle
    Start wind speed1.8m/s
    Reduced wind speed2.5m/s
    Survival wind speed50m/s
    Nominal power1.5 kW (13m/s)
    Nominal rotor speed750 rpm
    Maximum power2000W (20m/s)
    Working temperature range-40C to 60C
    Product life (years)15
    The level of acoustic pressureLAeq 33dB - 5m/s - 5m/s - 5m behind the rotor (air density of 1.225 kg/m3)
    GeneratorThree-phase, neodym-iron-bore-bore-type three-phase power generator
    Braking systemOff-grid 24V or 48V DC; on 48V DC network
    Lace controlElectromagnetic and aerodynamic aerodynamic braking system at higher speed than blade speed
    Management control360 degrees free
    Management controlRear tracing
    Control systemBraking mode
    Recommended systemNetwork control: lead-acid battery with deep discharge safety
    Note: At the start wind speed, it generates electricity, but it takes a higher wind speed to charge the battery or transfer it to the grid.




    Pylontech US5000 Lithium Battery +100 - 4.8kWhPylontech US5000 Lithium Battery +100 - 4.8kWh



    • A compact and trendy design that fits perfectly into your home environment.
    • Provides up to 4.8KW
    • Modular design to easily increase capacity.
    • Compatible with most hybrid inverters.
    • Security Cert.TüV CE UL UN38.3
    Save it to the Pylontech website allows you to extend the warranty to 10 years.
    * Battery connection cables to the inverter are sold separately.


    Characteristics


    Rated voltage48Vdc
    Rated capacity100 Ah
    Battery capacity4800 Wh
    Dod95%
    Dimensions (LxWxH)
    442x410x161 mm
    Weight39.7 kg
    Charging/discharging
    80 Ah (Recommended)
    120@ 15min (Max.)
    Current (A)
    200@15sec (peak)
    Communication portRS485, CAN
    SIngle string quantity16pcs
    Operating temperature0~50°C
    Shelf temperature-20~60°C
    Cycle life>6000, 25°C
    Authentication level
    UL1973/UL1642/UL9540A/VDE2510-50/IEC63056/IEC62619/IEC62040/IEC62477-1/IEC61000-6-2/UN38.3



    config-ac-6pan-éol
    498 Items

    Data sheet

    Inverter power
    5000VA
    Kit output voltage
    230V
    Type of need
    Off-grid
    Self-consumption
    Battery storage
    With storage
    Wind turbine
    With
    Number of panels
    6 panels
    Voltage
    230V
    Battery
    Kit with battery
    Panel type
    Rigids
    Mains re-injection
    off-grid

    Specific References

    UPC
    712971134768
    EAN13
    0712971134768
