Epever VS-AU Series VS1024AU 12/24 V 10A
Epever
More info
VS-AU Series VS1024AU
The VS-AU series is a PWM charge controller with LCD screen and two USB ports. When the gap between the operating voltage of the solar panel and the battery voltage is not large, the choice of this PWM series is an equally reliable but more cost-effective solution. It is widely applied to rural electrification and domestic power systems, etc.,
Characteristics
• Series PWM charging mode
• Full power working at working temperature range
• Multiple load control modes
• Adopt high quality, high-reliability international brand components
• Dual USB design
• LCD display design segment
• Real time energy statistics function
• Extensive electronic protection
Technical characteristics
| Model | VS1024AU |
| Rated system voltage | 12/24VDC Auto |
| Battery type | Sealed (default)/Freeze/Flooded |
| Battery input voltage range | 9V~32V |
| Nominal charging current | 10A |
| Rated discharge current | 10A |
| PV Open Circuit Voltage | 50V |
| Equalization voltage | Sealed: 14.6V, Flooded: 14.8V |
| Amplification voltage | Gel:14.2V,Sealed:14.4V,Flooded:14.6V |
| Floating voltage | Gel/Sealed/Flooded:13.8V |
| Low voltage reconnection voltage | Gel/Sealed/Flooded:12.6V |
| Low voltage disconnection voltage | Gel/Sealed/Flooded:11.1V |
| Self-consumption | ≤9.2mA/12V;≤11.7mA/24V;≤14.5mA/36V;≤17mA/48V |
| USB output | 5VDC/2.4A(Total) |
| Temperature compensation | '-3mV/°C/2V(25°C) |
| Relative humidity | ≤95%, N.C. |
| Case | IP30 |
| Grounding | Common positive |
| Operating temperature range | '-25°C~+55°C |
| Dimensions(WxWxH)(mm) | 142×85×41.5 |
| Net weight | 0.22kg |
Data sheets and documentation
Specifications
| 142 mm | |
| 12V / 24V | |
| 9V～32V | |
| 50 V | |
| 85 mm | |
| 41,5 mm | |
| 10 A |
