Park of 30 kWh batteries OPzV 48V View full size

Park of 30 kWh batteries OPzV 48V

Hoppecke

8 748,30 € tax incl.

Park of 24 Solar Batteries Hoppecke OPzV 620

The junctions necessary to connect your battery fleet are provided.

Available to order: 10 weeks delay



More details

More info

Hoppecke OPzS & OPzV

hoppecke opzv

> Park of 24 batteries Hoppecke opzv 620

> Battery capacity 30kWh

> Batteries are delivered charged and filled.

> The junctions necessary to connect your battery park are provided.

Opzv batteries are based on tubular plate technology with gel electrolyte fixation. These batteries are maintenance-free thanks to their sealed construction. Tubular plates offer a very high life expectancy to these batteries.

The opzv product range is optimal for application in sectors with a high number of discharges such as solar systems as well as for long discharge operations for example in IT / telecom or security lighting applications.


benefits



  • Optimal space utilization - by horizontal and vertical adjustment
  • Maintenance-free when it comes to water filling - by innovative gel technology
  • Very good cycle stability during use in PSoC1 - by the tubular design of the plates allows an efficient charging current
  • Maximum compatibility - measures that comply with DIN 40742
  • Enhanced short-circuit safety from the moment of assembly - by the use of HOPPECKE system connectors

Applications



  • On-grid and off-grid energy use
  • Drinking water treatment system
  • Medical treatment equipment
  • Signage, lighting
  • Mobile radio stations
  • Stations BTS
  • Off-grid/grid energy treatment systems

Cycling



Life expectancy up to 1500 cycles at 80% depth of discharge.


Cycle retention life depending on the capacity taken

Cycle retention life depending on the capacity taken


Technical specifications



Battery typeC100/1.85V
ah

C50/1.85V
ah

C24/1.83V
ah
C10/1.80V
ah
C5/1.77V
ah
Max weight* KgLength L max.* mmWidth l max.*mmHeight H max.* mmfig.
4 OPzV solar.power 250286,9263,5243,0204,1188,718,3105208420a
5 OPzV solar.power 310358,6329,3303,8255,1235,822,3126208420a
6 OPzV solar.power 370430,3395,2364,6306,1283,026,5147208420a
5 OPzV solar.power 420478,2452,9427,8391,4346,129,9126208535a
6 OPzV solar.power 520573,9543,4513,4469,7415,335,1147208535a
7 OPzV solar.power 620669,5634,0599,0548,0484,542,1168208535a
6 OPzV solar.power 750847,3802,2762,1682,0595,048,7147208710a
8 OPzV solar.power 10001129,81069,61016,2909,3793,365,9215193710B
10 OPzV solar.power 12501412,21337,01270,21136,7991,780,5215235710B
12 OPzV solar.power 15001694,71604,41524,21364,01190,094,6215277710B
10 OPzV solar.power 17001955,01870,01784,91544,61371,9110,0215277855B
16 OPzV solar.power 23002606,72493,32379,82059,51829,2152,9215400815c
20 OPzV solar.power 29003258,33116,72974,82574,32286,5186,5215490815D
24 OPzV solar.power 35003910,03740,03569,83089,22743,8222,3215580815D

C100, C50, C24, C10 and C5 = load capacity in 100, 50, 24, 10 and 5 hours

* in accordance with DIN 40742 these data are to be understood as the maximum values


Specifications

Type of needProsumer
Voltage24V
Battery capacity36 kWh
