300W Standalone Lighting Kit

Wattuneed

602,70 € tax incl.

Add to cart

Autonomous solar lighting kit.
Example of use: lighting of a horse box, garden, ...

Minimum 2 hours of lighting with 3 30W spots every day!



  • panel
  • batteries

More details

Équipements
Descriptions équipements
Customize

Choice of panels

See product
Solar Panel JNL solar monocrystalline 300 WC full black

config

150,26 €

QTT

Selecting the charge regulator

See product
Solar Regulator SRNE MPPT 12/24V 20A

config

60,01 €

QTT

See product
Solar Regulator SRNE MPPT 12/24V 30A

config

78,80 €

QTT

See product
Solar Controller MPPT 20A SRNE

config

76,60 €

QTT

See product
Solar Controller MPPT 30A SRNE

config

110,90 €

QTT

Choice of mounting system

49.1
Sélectionné

Mounting system for slates roof

55
Sélectionné

Mounting system for tile roof

127
Sélectionné

Free-land mounting kit for solar panel

37.28
Sélectionné

Mounting system for sheet metal

82.62
Sélectionné

Système de montage pour toitures plates FlatFix

42.84
Sélectionné

Mounting system for tray roofing

See product
Mounting system for slates roof

config

49,10 €

QTT

See product
Mounting system for tile roof

config

55,00 €

QTT

See product
Free-land mounting kit for solar panel

config

127,00 €

QTT

See product
Mounting system for sheet metal

config

37,28 €

QTT

See product
Système de montage pour toitures plates FlatFix

config

82,62 €

QTT

See product
Mounting system for tray roofing

config

42,84 €

QTT

Wiring and connections

See product
2X4mm² Solar cable with MC4 (5metre)

config

13,80 €

QTT

See product
2x4mm² Solar cable extension with 2xMC4 (by the meter)

config

7,30 €

QTT

See product
2X4mm² Solar cable with MC4 (by the metre)

config

68,80 €

QTT

See product
Male and female MC4 connectors

config

5,00 €

QTT

See product
Double MC4 connector male & female

config

16,00 €

QTT

See product
Earth cable 6mm2 1m

config

1,45 €

QTT

AC guards and accessories

See product
Schneider Breaker mono 2A

config

13,13 €

QTT

See product
Schneider Breaker mono 4A

config

13,13 €

QTT

See product
Schneider Breaker mono 6A

config

13,31 €

QTT

See product
Schneider Breaker mono 10A

config

16,50 €

QTT

See product
Schneider Breaker mono 16A

config

8,13 €

QTT

See product
Schneider Breaker mono 20A

config

8,13 €

QTT

See product
Schneider Breaker mono 25A

config

14,48 €

QTT

See product
Schneider Breaker tetra 16A

config

39,69 €

QTT

See product
Schneider Breaker tetra 20A

config

39,69 €

QTT

See product
Schneider Breaker tetra 25A

config

39,69 €

QTT

See product
Schneider Breaker tetra 40A

config

45,74 €

QTT

See product
Schneider Breaker tetra 50A

config

183,68 €

QTT

DC guards and accessories

See product
DC 500V 32A Switch with door clutch

config

32,90 €

QTT

See product
DC 2P 1000V 32A Switch - with enclosure

config

56,00 €

QTT

See product
ZJBENY DC single-surge arrestor box

config

143,00 €

QTT

See product
ZJBENY double DC surge-arrestor box

config

231,00 €

QTT

See product
Paralleling Box 5 inputs with lightning arrester and switch

config

270,00 €

QTT

See product
DC 500V 32A Switch box

config

129,00 €

QTT

See product
DC 500V 40A Switch

config

68,00 €

QTT

See product
DC Cut-out and lightning protection box 20A

config

262,85 €

QTT

See product
Double DC Cut-out and lightnin protection box

config

551,98 €

QTT

Choice of battery

See product
Ultracel GEL battery 12V 100Ah

config

199,00 €

QTT

See product
GEL battery Ultracell 12V 35Ah

config

86,70 €

QTT

See product
Ultracell 12V 55Ah GEL battery

config

139,37 €

QTT

See product
Ultracel GEL battery 12V 150Ah

config

294,43 €

QTT

See product
Ultracel GEL battery 12V 200Ah

config

397,00 €

QTT

See product
Ultracel GEL battery 12V 250Ah

config

534,40 €

QTT

ACCESSORY SELECTION

See product
LCD RM-6 display for MPPT SRNE controller

config

33,00 €

QTT

See product
16mm² battery cable with pods

config

5,80 €

QTT

See product
25mm² battery cable with pods

config

9,00 €

QTT

See product
Double 4mm² battery cable 2m

config

9,90 €

QTT

See product
LED spot 30W - 12V

config

58,50 €

QTT

See product
LED spot 50W - 12V

config

96,80 €

QTT

See product
LED spot 10W - 12V

config

22,20 €

QTT

See product
Spot LED Flood Light 10W

config

31,90 €

QTT

See product
Spot LED Flood Light 30W

config

30,59 €

QTT

See product
Spot LED Flood Light 50W

config

73,80 €

QTT

More info

Autonomous solar lighting kit for a horse box or cabin

Composition


This kit will produce at least 205 Wh in Paris, which represents 2 hours of use of the three spots!
The battery has a useful capacity of 450Wh (at 30% discharge to optimize its life, 1200 cycles).



Our kit comes ready to be installed. We wire the connections, we can adapt the lengths on demand






Solar panel JNL Solar Monocristallin 300 Wc Full Black



NL Solar is dedicated to the development, operation, maintenance of solar power plants, the manufacture of research and development rings and the manufacture of solar modules and solar cells. It has equipped a state-of-the-art professional automatic production line and has state-of-the-art technology and craftsmanship.
JNL Solar has participated in national and international energy investment plans, such as the United States, Germany, France, Spain, Japan, India, South Africa, South Korea, Canada, etc. and all power plants are successful on the grid and production wells.









 Characteristics



Weight18.5 kg
ColorFull Black
Panel typeRigid/traditional
CellsMonocrystalline
Maximum Power - Wc300
Open-circuit tension (Voc)39.53 V
Short-circuit current (Isc)9.6 A
Maximum Power Current (Imp)8.95 A
Max power voltage (Vmp)33.54 V
Panel yield18,33%
Width992 mm
Height1650 mm
Framework35 mm

Solar Regulator SRNE MPPT 12/24V 20A



Using PowerCatcher MPPT technology, the MC Series solar charging controller tracks maximum energy for solar panels. This technology allows the controller to quickly and accurately track the maximum power point of a photovoltaic installation in any environment, to obtain the maximum production of a solar panel in real time and to greatly increase the energy efficiency of the solar system.





Characteristics



ArticlesParameter
ModelMC2420N10
Tension of the system12/24V
Zero load loss10mA
Battery voltage9V-32V
Maximum open-circuit PV voltage92V (25oC); 100V (Lowest ambient temperature)
Maximum voltage range at power point20A
Nominal charge current260W/12V 520W/24V
Maximum PV input power
Load conversion return99%
Temperature compensation coefficient-3mv/C/2V (defect); Lithium battery without temperature compensation
Operating temperature-35C / 60C
IP ratingIp32
Weight of the device600g
How to communicateCommunication series TTL
Altitude
Dimensions (mm)150*105.6*61.5



Gel 100Ah Batteries

Gel batteries are waterproof batteries: no maintenance, no addition of distilled water. Enhanced safety compared to open lead batteries.
A gel battery can withstand 100% discharge and regain its rated capacity if the discharged maintenance time is short. This series has a longer discharge time compared to other batteries. Its special plate design increases battery life and especially in warmer temperatures. A separator within the battery improves performance. It also has a longer shelf life.

  • Nominal voltage: 12V
  • Capacity: 100Ah
  • Dimensions: 327 x 173 x 212 mm
  • Weight: 31 Kg





Life cycle relative to discharge depth



cycles de vie batterie gel 65Ah


spot led 30W





3X Spots LED 30W



-Our black aluminum exterior LED projectors allow for powerful and economical wide-angle lighting.

-The waterproofing of the aluminium case and the thick protective glass makes it possible to mount it without special protection.

-They are also ideal indoors for lighting garages and commercial premises, but also indirect lighting for high-rise ceilings or skylights.

-Equivalent to 200W halogen, our latest generation LED projectors are perfect for powerfully illuminating your trees and gardens.

-Food: 12v DC (Requires a special LED power supply 12v DC).









  • Power: 30W
  • Color: warm white
  • Light flow: 2400lm
  • Color temperature: 2700-3500K
  • Dimensions: 225x183x125mm
  • Weight: 2.8 kg
  • IP Index: 65
  • Operating range: -20 - 50 degrees
  • Number of LEDs: Multichips COB
  • LED type: High Power 30w COB

Wiring

câble solaire



5m 2X4mm2 solar cable with mc4 connectors set on cable

2m battery cable with served battery pod






















WATTUNEED'S OPINION

Essential kit for those whose available space is limited and who really need power.



Optional: assembly system

 crochet de fixationcrochet de fixation

1. Roofing

  • Stainless stainless steel fastening hook for laying on slate roof
  • Stainless crochet for laying on a tile roof.

     These hooks attach to the woodwork and are used to secure the aluminum rail used to support the solar panels.



boulonsboulons



  • Stainless hexagonal head screw, total net M10x25 DIN 933 A2
  • din 934 A2 M10 stainless steel hexagonal nut





rail de fixation des panneaux solaires



Aluminium rails, profile size: 40X40mm



clame de fixation panneau solaireclame de fixation panneau solaire



Fixing clams to attach panels to rails

  • Middle clame
  • End Clame

Slip into aluminum rail with bolt and stainless steel nut (supplied)





 Yes



2. Ground structure

support aluminium



Adjustable aluminum support (15-20-25-30-35)









clame de fixation panneau solaireclame de fixation panneau solaire



Fixing clams to attach panels to rails

  • Middle clame
  • End Clame



Slip into aluminum rail with bolt and stainless steel nut (supplied)
