SMA Sunny Tripower STP 15000TL-30TL without screen View full size

SMA Sunny Tripower STP 15000TL-30TL without screen


3 918,65 € tax incl.

SMA Sunny Tripower 15000TL three-phase inverter.
Suitable for almost all modular configurations thanks to Optiflex technology with two MPP inputs and a very wide range of input voltage.

To know the delivery time, you can contact us by chat, email or phone.

More details

More info

SMA Sunny Tripower STP 15000TL



SMA Sunny Tripower STP 15000TL



  • Maximum return of 98.2%
  • Search for maximum power point optimized with SMA's MPP OptiTrac Global Peak regulation
  • Bluetooth communication®



  • Triple protection thanks to Optiprotect: Electronic string fuse, Detection of the dysfunction of self-learning thongs, Integrable DC Parafoudre (Type II)



  • DC input voltage up to 1,000 V
  • Integrated network management
  • Flexible installation size with Optiflex



  • Three-phase injection
  • Connecting cables without tools
  • DC SUNCLIX Connection System
  • Easy-to-access connection area

 Efficiency curve sunny tripower 17000TL


Power curve

Optitrac technology

Optitrac technology


OptiTrac Global Peak is an additional feature of the proven "OptiTrac" MPP tracker and is activated on this inverter

This is used in the case of partially shaded photovoltaic installations. Even in this configuration, this special operating mode ensures that the panels operate continuously at the maximum power point, with no significant impact on performance (loss of 0.2%). Aurement says: even in case of shading the panels work properly.



Sunny Tripower15000TL
Dc Power Max. (for cos ?-1)15340 W
Maximum input voltage.1000 V
MPP voltage range /assigned input voltage360 V - 800 V / 600V
Min./start input voltage150 V / 188 V
Entry current max. entry A / entry B33 A / 11 A
Entry current max. by thong input A / entry B40 A / 12.5 A
Number of independent MPP entries / strings per MPP entry2 / A: 5; B: 1
Assigned power (at 230V, 50 Hz)15000W
Apparent power AC max.15,000 VA
AC nominal voltage3 / N / PE; 220 / 380 V
3 / N / PE; 230 / 400 V
3 / N / PE; 240 / 415 V
AC rated voltage range160 V to 280 V
AC/beach frequency50 Hz, 60 Hz / -6 Hz ... 5 Hz
Assigned network frequency/tension50 Hz / 230 V
Outfing current max.24 A
Power factor to assigned power1
Adjustable phase-shift factor0 inductive ... 0 capacitive
Injection/connection phases3 / 3
Maximum return / European return98,2 % / 97,8 %
D.C. side disconnection deviceYes
Monitoring the ground/network defectYes / Yes
DC polarity reversal protection / AC short-circuit resistance/galvanic separationYes / Yes / —
Defect current monitoring unit sensitive to all currentsYes
Protective class (according to IEC 62103) / surge category (according to IEC 60664-1)I/III
Dimensions (L/H/P)665 / 690 / 265 mm
(26.2 / 27.2 / 10.4 inches)
Weight59 kg / (130.17 lbs)
Operating temperature range-25 degrees Celsius ... -60 degrees Fahrenheit
(-13 degrees Fahrenheit ... -140 degrees Fahrenheit)
Noise emissions (typical)51 dB (A)
Self-summoning (night)1 W
Topology / cooling principleNo Transformer / OptiCool
Protection Index (according to IEC 60529)IP65
Climate category (according to IEC 60721-3-4)4K4H
Maximum allowable relative moisture value (without condensation)100 %
DC Connection / AC ConnectionSUNCLIX / spring terminal
Interface: RS485 /Bluetooth / WebconnectOptional / Yes / Optional
Multifunction Relay / Power Control ModuleOptional
Guarantee: 5 / 10 / 15 / 20 / 25 yearsYes / Optional / Optional / Optional / Optional
Certifications and certifications (other on request)AS 4777, BDEW 2008, C10/11:2012, CE, CE 0-16, CEI 0-21, EN 504381, G59/3, IEC 61727 (MEA/PEA), IEC 62109-1/2, NEN 50438, PPC, PPDS, RD 1699, RD 661/2007, SI4777, UTE C15-712-1, VDE 0126-1-1, VDE-AR-N 4105
Type designationSTP 15000TL-10


Maximum PV input voltage1000 V
Power15340 VA
Monophasé / TriphaséTriphasé
Nombre de MPPT1 MPPT
