Mono Sofar Solar 1100TL INverter

Sofar Solar

315,00 € tax incl.

High yield 97.2%

All-in-one solution, felxible and economical system

Reduced cost and maintenance

Smart Grid Management



The warranty extension available in the options only covers the manufacturer's inverter and not the cost of transporting the unit.
Transportation is the responsibility of the buyer.

stock quantity : 1

More details

More info

 Presentation of the inverter: Sofar 1100TL. Grid connected inverter


Warranty extension



The warranty extension available in the options only covers the manufacturer's inverter and not the cost of transporting the unit.
Transportation is the responsibility of the buyer.


High yield



Maximum efficiency of 97%.
Accurate real-time MPPT algorithm for maximum operation
Wide range of operation of input voltage


All in one. Flexible and economical system solution



Choosing the free location with the IP65
Easy installation and maintenance with the "Plug - Play" connection
Interface Selection - Wi-Fi / RS485 /GPRS
4-inch LCD screen
Built-in zero-export function (optional)


Low maintenance cost



Detachable lid for easy installation
Stainless aluminum blankets
A flexible control solution


Smart power grid management



Reactive power capacity
Self-reducing power in case of over-frequency
Remote control of the active/reactive power limit


 Efficiency curve



 Efficiency curve



 Characteristics



Model1100
Entry (DC)
Max. Recommended Recommended PV Entry Power Recommended1470W
Max. Entry Tension450V
Number of MPPT/chain by MPPT1/1
Start-up tension100V
Nominal input voltage360V
MPPT operating voltage range80-455V
Full-power MPPT voltage range105-380V
Max. Entry current10A
Current DC maximum short-circuit entry by MPPT12.5a
Production (AC)
Nominal power1000w
Maximum power in alternating current1000VA
Max. CA Output Current4;5a
Nominal network voltageL/N/PE,220Vac,230Vac,240Vac
Network voltage range180Vac-275Vac (according to local standard)
Nominal frequency50 Hz/60Hz
Network frequency range45Hz-55Hz/54Hz-66Hz (According to local standards)
THDi3%
Power factor1Defut (adjustable - 0.8)
Limiting power exportZero export or adjustable power limit export
Efficiency
Max. Efficiency97,00%
European weighted efficiency95.2%
Effectiveness of ADAPTATION of PTSD$99.9%
Protection
Protection from isletingYes
Protection against polarity reversal in direct currentYes
Protection from overworkYes
Leakage protectionYes
Surge protectionYes
Protection from over-intensitiesYes
Protection from defects to the earthYes
SpdMOV:type III Standard
Communication
Standard mode of communicationRs485,Wifi/internet/GPRS (optional), SD card (optional)
Storage of operating dataAge 25
I/OYes
General data
TopologyNo transformer
Room temperature range-30 degrees Celsius, 60 degrees Fahrenheit
Allowed relative humidity range0-100%
Noise25dB
DC SwitchOptional
CoolingNatural
Maximum operating altitude2000m
Dimension405-314-135 mm
Nocturnal self-consumption1W
Weight11 kg
DisplayLcd
Degree of protectionIP65
Warranty5 years old
Standard
EmcEN61000-6-2, EN61000-6-3,EN61000-3-3
Safety standardsIEC 62109-1/2,IEC62116, IEC61727, IEC-61683, IEC60068 (1.2,14.30)
Grid standardsAS/NZS 4777, VDE V0124-100, VDE0126-1-1, VDE-AR-N 4105, CEI 0-21, ENS0438/ENS0549, G98/G83, C10/11, RD1699, UTE C15-712-1: ABNT NBR 16149/16150

Specifications

MPPT/PWMMPPT
Monophasé / TriphaséMonophasé
Inverter power1550 VA
