SMA Sunny Tripower STP 6.0 TL INT BLUE - Zero Injection

SMA

2 692,30 € tax incl.

SMA Sunny Tripower three-phase inverter - model: 6.0TL
This inverter is optimal for both traditional residential photovoltaic installations and much more powerful installations.

SMA Sunny Home Manager 2.0, which blocks the re-injection of excess production into the public network.

More details

More info

SMA Sunny Tripower STP 6.0 TL INT BLUE - Zero InjectionDescription



Economic

  • Maximum return of 98%
  • Shading management with Opti-Trac Global Peak
  • Active temperature management with OptiCool



Flexible

  • DC input voltage up to 1000 V
  • Integrated network management features
  • Reactive power injection
  • Precise sizing of the installation modules with Optiflex



Interactive

  • SMA Webconnect
  • Integrated ethernet communication with Sunny Portal
  • Communication Bluetooth®
  • Easy to adjust regional parameters
  • Series multifunction relay



Simple

  • Three-phase injection
  • Connecting cables without tools
  • DC SUNCLIX Connection System
  • ESS built-in DC switch-sectionor
  • Simple wall mounting

SMA Sunny Home Manager 2.0SMA Sunny Home Manager 2.0



Sunny Home Manager 2.0 monitors all energy flows in the home, automatically identifies savings potentials and makes efficient use of solar energy. The new Sunny Home Manager 2.0 will bring together the functions of Sunny Home Manager Bluetooth and SMA Energy Meter in one device, for even simpler and more economical intelligent energy management.





Optitrac

Optitrac



OptiTrac Global Peak is an additional function of the MPP tracker for operation in partially shaded PV installations.
This system specialized in operating management ensures that the modules are constantly operated to the maximum power, even in the presence of several maximum powers (in the case of partially shady photovoltaic systems), without loss of measurable performance (loss <0.2%), . In other words, even if the shading panels work properly.


 Characteristics



Technical featuresSunny Tripower 3.0Sunny Tripower 4.0Sunny Tripower 5.0Sunny Tripower 6.0
Entry (DC)6000 Wc8000 Wc9000 Wc9000 Wc
Maximum power of the photovoltaic generator850 V
Maximum input voltage.140 V to 800 V175 V to 800 V215 V to 800 V260 V to 800 V
MPP voltage range580 V
Assigned input voltage125 V / 150 V
Min. input voltage / start input voltage Entry current max. A/entry B12 A / 12 A
Current short-circuit max. entrance A / entrance B18 A / 18 A
Number of independent MPP entries / strings per MPP Output entry (AC)2 / A:1; B:1
Assigned power (for 230V, 50 Hz)3000 W4000 W5000 W6000 W
Apparent power AC max.3000 VA4000 VA5000 VA6000 VA
AC nominal voltage3/N/PE; 220 V / 380 V 3/N/PE; 230 V / 400 V 3/N/PE; 240 V / 415 V
AC voltage range 180 V to 280 V
Frequency of AC/Beach50 Hz / 45 Hz at 55 Hz 60 Hz / 55 Hz at 65 Hz
Assigned network frequency/assigned network voltage50 Hz / 230 V
Outfing current max.3 x 4.5A3 x 5.8 A3 x 7.6A3 x 9.1 A
Power factor to assigned power / adjustable phase shift factor Injection phases / Connection phases1/0.8 inductive to 0.8 capacitive
Performance
Maximum return / European return98,2 % / 96,5 %98,2 % / 97,1 %98,2 % / 97,4 %98,2 % / 97,6 %
Protective devices
Disconnection device on the entry side
Ground defect monitoring/network monitoring●/●
DC polarity reversal protection / AC short-circuit resistance/galvanic separation●/●/-
Fault current monitoring unit, sensitive to all currents Protection class (according to IEC 62103) / surge category (according to IEC 60664-1)
Protective class (according to IEC 62103) / surge category (according to IEC 60664-1)I/III
General features
Dimensions (L/H/P)435 mm / 470 mm / 176 mm (17.1 inches / 18.5 inches / 6.9 inches)
Weight17 kg (37.4 lbs)
Operating temperature range '25' to '60' ('13' to '140'
Typical sound emissions30 dB (A)
Self-consumption (night)5.0 W
Topology / Cooling SystemNo Transformer / Convection
Protection Index (according to IEC 60529)IP65
Climate class (according to IEC 60721-3-4)4K4H
Maximum allowable value for relative air humidity (without condensation) Equipment100,00%
Equipment
DC Connection / AC ConnectionSUNCLIX / fiche AC
Display via smartphone, tablet, laptop
Interfaces: WLAN / Ethernet / RS485●/●/●
Communication protocolsModbus (SMA, Sunspec), Webconnect, SMA Data, TS4-R
Shading Management: OptiTrac Global Peak / TS4-R●/○
Guarantee: 5 / 10 / 15 years●/○/○
Certifications and certifications (other on request)AS 4777, C10/11, CE, CE, CE 0-21, DIN EN 62109-1/IEC 62109-1, DIN EN 62109-2,2009-2, 50438, G59/3, G83/2, NEN-EN 50438, EVE / 'NUMM E 8001-4-712, PPDS, PPC, RD 1699, SI 4777, TR 3.2.1, UTE C15-712, VDE-AR-N 4105, VDE-0126-1-1-1, VFR 2014
Certifications and approvals (in project)DEWA 2016, 62116, IEC 61727, IE-EN 50438, NBR 16149, NRS 097-2-1
SMA Smart Connected Availability CountryAU, AT, BE, CH, DE, ES, EN, IT, LU, NL, UK
Type designationSTP3.0-3AV-40STP4.0-3AV-40STP5.0-3AV-40STP6.0-3AV-40

Specifications

Maximum PV input voltage1000 V
Monophasé / TriphaséTriphasé
Nombre de MPPT2 MPPT
Inverter power6000VA
