SolarEdge Compact SE1000M to SE2000M View full size

SolarEdge Compact SE1000M to SE2000M

SolarEdge

623,57 € tax incl.

Options

The single-phase inverter with compact technology is an economical solution of DC inverters optimized for residential, which is ideal for homes with limited roof space, social housing projects, or to meet minimum requirements in terms of sustainability.



Please choose your model from the options.

More details

More info

Technology compact


A Green Electricity - Affordable For Small Resident roofs


The single-phase inverter with compact technology is an economical solution of DC inverters optimized for residential, which is ideal for homes with limited roof space, social housing projects, or to meet minimum requirements in terms of sustainability.

Benefiting from the many SolarEdge advantages such as greater energy collection of each module, long-term product guarantees, advanced security features and free module-level supervision1 , the single-phase inmoner With compact technology can be easily installed on existing roofs or on new buildings and provides clean energy, which is both affordable, efficient and safe.

A Green Electricity - Affordable For Small Resident roofs


Designed specifically for roofing systems with 4-8 modules


The solution includes a single power optimizer with four maximum power point controllers (or Maximum Power Point Trackers, MPPT) to collect more energy produced by each module. One or two 60-cell PV modules or a 72/96 cell PV module can be connected at each input. The M2640 power optimizer works exclusively with the new compact-technology single-phase iner. The wall inunner is extremely compact, very light, easy to install and available in three versions: 1 kW, 1.5 kW and 2 kW.


Key features


• Power optimizer and inunntor designed exclusively to work together
• Extremely compact, very light, easy to install
• Fast and easy to get the inletor ready directly from your smartphone using SolarEdge SetApp
• More security with SafeDC™, designed to reduce the system's voltage to 10V for maximum PV security
• IP65 inser—suitable for indoor and outdoor installation
• Two different inducing options are available depending on the project requirements, for maximum profitability:
• Basic — for facilities where supervisory connectivity is not required
• Extended — for facilities requiring supervisory connectivity
• Ethernet and Wi-Fi2 integrated
• Additional connectivity options such as ZigBee® and cellular network plug-in can be purchased separately
• The connection to smart energy products and energy meters is also supported


Size

Size


Characteristics



modelSE1000MSE1500MSE2000Mvalue
exit
Maximum AC output power100015002000Will
AC output voltage (nominal)220/230Vac
AC exit voltage range184-264,5Vac
AC frequency (nominal)50/60 -5Hz
Maximum continuous output intensity579,5Has
entrance
Maximum DC Power135020252640W
Without trasnformateur, without groundingyes
Maximum entry tension500Vdc
Running tension75-480Vdc
Maximum entry current.11Adc
Maximum return. From the indutor97%
Weighted European return95,796,597%
Installation specification
Dimensions (HxLxP)340 x 239 x 127Mr
noise25Dba
weight6Kg
coolingNatural convection
Operating temperature range -40 to 60
Protection index IP65 - outdoors and indoors



Specifications

Weight10 kg
Weight11,9 kg
Weight11,4 kg
Monophasé / TriphaséMonophasé
Width370 mm
Height450 mm
Thickness174 mm
AC output rated power2 200VA; 3 000VA; 3 500VA; 3 680VA; 4 000VA; 5 000VA; 6 000VA
Maximum DC power3400W; 4650W; 5425W; 5700W; 6200W; 7750W; 9300W
