Mistral Unit Outdoor heat pump air/water 10 to 17
€2,629.69
Tax included
AIR10-17
0768563819520
• Heat pumps perfectly adapted for heating outdoor swimming pools up to 100 m³
• Rotary compressor
100% secure payments
SWI outdoor air/water heat pump
Equipment
ABS bodywork: durable and corrosion-resistant design
Blue Fins Evaporator: corrosion resistant and with rapid defrosting process
Automatic hot gas defrosting (SAGINOMIYA 4-way cycle reversal valve)
Works up to an outside air temperature of 0°C
Titanium heat exchanger
Installation
Outside and near the technical room
Hydraulic connection in PVC Ø 50 by by-pass on filtration
Provide a clearance of 30 cm between the back of the heat pump and the wall or hedge
There must be no obstacle in front of the machine for 3 meters (wall, hedge ...)
Power supply with 30 mA differential circuit breaker protection at the head of the line (not included)
Characteristics
| AQUA AIR INVERTER | COMFORT INVERTER | |||||
| Model | AIR10 | AIR13 | AIR15 | AIR17 | 14-3219 | |
| Power returned (26°C) | Kw | 10,3 | 12,8 | 15 | 12,8 | 20 |
| Power consumption (26°C) | Kw | 0.71~1.49 | 0.85~1.73 | 0.97~2.24 | 1.17~2.93 | 1.89 ~ 3.57 |
| COP | 14.5~6.9 | 15~7.4 | 15.5~6.7 | 14.8~5.9 | 10.6~5.6 | |
| COP at 50% | 10,4 | 11 | 10,9 | 10,5 | 8,9 | |
| Power returned (15°C) | Kw | 7,1 | 8,9 | 10,5 | 11,4 | 14 |
| Power consumption (15°C) | Kw | 0.19~1.5 | 0.22~1.73 | 0.27 ~ 2.2 | 0.3~2.6 | 2.33 ~ 3.41 |
| COP | 7.3~4.6 | 7.7~4.8 | 7.8~4.6 | 7.5~4.3 | 6~4.1 | |
| COP at 50% | 6,4 | 6,8 | 6,6 | 6,1 | 5,8 | |
| Max. volume pool | m³ | 25-45 | 30-55 | 35-65 | 40-75 | 45-85 |
| Operating limits | 0° ~ 43°C | |||||
| Power supply | V/Ph/Hz | 230/1/50 + T | 230/1/50 + T | |||
| Sound pressure level at 10m | dB(A) | 18,6-29,9 | 22,1-30,7 | 21,3-30,4 | 23,1-33,8 | 230/1/50 + T |
| Dimensions (HxWxD) | mm | 658x961x340 | 658x961x340 | 658x961x340 | 658x961x420 | 748x954x359 |
| Weight | Kg | 49 | 50 | 52 | 63 | 68 |
AIR10-17
1 Items
Data sheet
- Width
- 880 mm
- Height
- 793 mm
- Thickness
- 310 mm
- Weight
- 62 kg
Specific References
- UPC
- 768563819520
- EAN13
- 0768563819520
